Johnson Controls York YKEP Series User Manual

FORM 160.77-O2
ISSUE DATE: 11/15/2011
SECTION 4 - MODBUS RTU SLOT LIST
JOHNSON CONTROLS
105
4
Modbus DF1 Count Logix Tag Description
10458 N12:22/6 358 SSS_LS.Alarms[1].6 PRI SSS FAULT: SPARE WORD1 BIT6
10459 N12:22/7 359 SSS_LS.Alarms[1].7 PRI SSS FAULT: SPARE WORD1 BIT7
10460 N12:22/8 360 SSS_LS.Alarms[1].8 PRI SSS FAULT: SERIAL RECEIVE ERROR
10461 N12:22/9 361 SSS_LS.Alarms[1].9 PRI SSS FAULT: INHIBIT START HIGH TEMPERATURE
10462 N12:22/10 362 SSS_LS.Alarms[1].10 PRI SSS FAULT: SPARE WORD1 BIT10
10463 N12:22/11 363 SSS_LS.Alarms[1].11 PRI SSS FAULT: POWER SUPPLY FAILURE
10464 N12:22/12 364 SSS_LS.Alarms[1].12 PRI SSS FAULT: PHASE ROTATION
10465 N12:22/13 365 SSS_LS.Alarms[1].13 PRI SSS FAULT: CONTACTOR FAULT
10466 N12:22/14 366 SSS_LS.Alarms[1].14 PRI SSS FAULT: GROUND FAULT
10467 N12:22/15 367 SSS_LS.Alarms[1].15 PRI SSS FAULT: CONTROL BOARD
10468 N12:23/0 368 SSS_LS.Alarms[2].0 PRI SSS Read Fail
10469 N12:23/1 369 SSS_LS.Alarms[2].1 PRI SSS Write Fail
10470 N12:23/2 370 SSS_LS.Alarms[2].2 PRI SSS Read TRIP
10471 N12:23/3 371 SSS_LS.Alarms[2].3 PRI SSS: SPARE W2 B3
10472 N12:23/4 372 SSS_LS.Alarms[2].4 PRI SSS: SPARE W2 B4
10473 N12:23/5 373 SSS_LS.Alarms[2].5 PRI SSS: SPARE W2 B5
10474 N12:23/6 374 SSS_LS.Alarms[2].6 PRI SSS: SPARE W2 B6
10475 N12:23/7 375 SSS_LS.Alarms[2].7 PRI SSS: SPARE W2 B7
10476 N12:23/8 376 SSS_LS.Alarms[2].8 PRI SSS: SPARE W2 B8
10477 N12:23/9 377 SSS_LS.Alarms[2].9 PRI SSS: SPARE W2 B9
10478 N12:23/10 378 SSS_LS.Alarms[2].10 PRI SSS: SPARE W2 B10
10479 N12:23/11 379 SSS_LS.Alarms[2].11 PRI SSS: SPARE W2 B11
10480 N12:23/12 380 SSS_LS.Alarms[2].12 PRI SSS: SPARE W2 B12
10481 N12:23/13 381 SSS_LS.Alarms[2].13 PRI SSS: SPARE W2 B13
10482 N12:23/14 382 SSS_LS.Alarms[2].14 PRI SSS: SPARE W2 B14
10483 N12:23/15 383 SSS_LS.Alarms[2].15 PRI SSS: SPARE W2 B15
10484 N12:24/0 384 VSD_LS.Alarms[0].0 PRI VSD FAULT: PRECHARGE DC BUS VOLTAGE
IMBALANCE BU
10485 N12:24/1 385 VSD_LS.Alarms[0].1 PRI VSD FAULT: PRECHARGE DC BUS VOLTAGE
IMBALANCE AL
10486 N12:24/2 386 VSD_LS.Alarms[0].2 PRI VSD FAULT: PRECHARGE DC BUS VOLTAGE
IMBALANCE AU
10487 N12:24/3 387 VSD_LS.Alarms[0].3 PRI VSD FAULT: DC BUS VOLTAGE IMBALANCE CL
10488 N12:24/4 388 VSD_LS.Alarms[0].4 PRI VSD FAULT: DC BUS VOLTAGE IMBALANCE CU
10489 N12:24/5 389 VSD_LS.Alarms[0].5 PRI VSD FAULT: DC BUS VOLTAGE IMBALANCE BL
10490 N12:24/6 390 VSD_LS.Alarms[0].6 PRI VSD FAULT: DC BUS VOLTAGE IMBALANCE BU
10491 N12:24/7 391 VSD_LS.Alarms[0].7 PRI VSD FAULT: DC BUS VOLTAGE IMBALANCE AL
10492 N12:24/8 392 VSD_LS.Alarms[0].8 PRI VSD FAULT: DC BUS VOLTAGE IMBALANCE AU
10493 N12:24/9 393 VSD_LS.Alarms[0].9 PRI VSD FAULT: POWER TRANSFORMER HIGH TEMP
10494 N12:24/10 394 VSD_LS.Alarms[0].10 PRI VSD FAULT: MAIN CONTROL BOARD FAULT
10495 N12:24/11 395 VSD_LS.Alarms[0].11 PRI VSD FAULT: INITIALIZATION FAILED
10496 N12:24/12 396 VSD_LS.Alarms[0].12 PRI VSD FAULT: HIGH PHASE C INVERTER
BASEPLATE TEMP
10497 N12:24/13 397 VSD_LS.Alarms[0].13 PRI VSD FAULT: HIGH PHASE B INVERTER
BASEPLATE TEMP
