FORM 160.77-O2
ISSUE DATE: 11/15/2011
JOHNSON CONTROLS
106
SECTION 4 - MODBUS RTU SLOT LIST
Modbus DF1 Count Logix Tag Description
10498 N12:24/14 398 VSD_LS.Alarms[0].14 PRI VSD FAULT: HIGH PHASE A INVERTER
BASEPLATE TEMP
10499 N12:24/15 399 VSD_LS.Alarms[0].15 PRI VSD FAULT: HIGH INSTANTANEOUS CURRENT
10500 N12:25/0 400 VSD_LS.Alarms[1].0 PRI VSD FAULT: GATE DRIVER CMU
10501 N12:25/1 401 VSD_LS.Alarms[1].1 PRI VSD FAULT: GATE DRIVER CNL
10502 N12:25/2 402 VSD_LS.Alarms[1].2 PRI VSD FAULT: GATE DRIVER CNU
10503 N12:25/3 403 VSD_LS.Alarms[1].3 PRI VSD FAULT: GATE DRIVER BML
10504 N12:25/4 404 VSD_LS.Alarms[1].4 PRI VSD FAULT: GATE DRIVER BMU
10505 N12:25/5 405 VSD_LS.Alarms[1].5 PRI VSD FAULT: GATE DRIVER BNL
10506 N12:25/6 406 VSD_LS.Alarms[1].6 PRI VSD FAULT: GATE DRIVER BNU
10507 N12:25/7 407 VSD_LS.Alarms[1].7 PRI VSD FAULT: GATE DRIVER AML
10508 N12:25/8 408 VSD_LS.Alarms[1].8 PRI VSD FAULT: GATE DRIVER AMU
10509 N12:25/9 409 VSD_LS.Alarms[1].9 PRI VSD FAULT: GATE DRIVER ANL
10510 N12:25/10 410 VSD_LS.Alarms[1].10 PRI VSD FAULT: GATE DRIVER ANU
10511 N12:25/11 411 VSD_LS.Alarms[1].11 PRI VSD FAULT: PRECHARGE LOW DC BUS VOLTAGE
10512 N12:25/12 412 VSD_LS.Alarms[1].12 PRI VSD FAULT: HIGH OUTPUT FREQUENCY
10513 N12:25/13 413 VSD_LS.Alarms[1].13 PRI VSD FAULT: PRECHARGE DC BUS VOLTAGE
IMBALANCE CL
10514 N12:25/14 414 VSD_LS.Alarms[1].14 PRI VSD FAULT: PRECHARGE DC BUS VOLTAGE
IMBALANCE CU
10515 N12:25/15 415 VSD_LS.Alarms[1].15 PRI VSD FAULT: PRECHARGE DC BUS VOLTAGE
IMBALANCE BL
10516 N12:26/0 416 VSD_LS.Alarms[2].0 PRI VSD FAULT: SINGLE PHASE INPUT POWER
10517 N12:26/1 417 VSD_LS.Alarms[2].1 PRI VSD FAULT: CONTACTOR FAULT
10518 N12:26/2 418 VSD_LS.Alarms[2].2 PRI VSD FAULT: LOSS OF COOLING FAN
10519 N12:26/3 419 VSD_LS.Alarms[2].3 PRI VSD FAULT: 105% MOTOR OVERLOAD CURRENT
10520 N12:26/4 420 VSD_LS.Alarms[2].4 PRI VSD FAULT: LOW DC BUS VOLTAGE
10521 N12:26/5 421 VSD_LS.Alarms[2].5 PRI VSD FAULT: HIGH DC BUS VOLTAGE CL
10522 N12:26/6 422 VSD_LS.Alarms[2].6 PRI VSD FAULT: HIGH DC BUS VOLTAGE CU
10523 N12:26/7 423 VSD_LS.Alarms[2].7 PRI VSD FAULT: HIGH DC BUS VOLTAGE BL
10524 N12:26/8 424 VSD_LS.Alarms[2].8 PRI VSD FAULT: HIGH DC BUS VOLTAGE BU
10525 N12:26/9 425 VSD_LS.Alarms[2].9 PRI VSD FAULT: HIGH DC BUS VOLTAGE AL
10526 N12:26/10 426 VSD_LS.Alarms[2].10 PRI VSD FAULT: HIGH DC BUS VOLTAGE AU
10527 N12:26/11 427 VSD_LS.Alarms[2].11 PRI VSD FAULT: GROUND FAULT
10528 N12:26/12 428 VSD_LS.Alarms[2].12 PRI VSD FAULT: INPUT POWER SUPPLY
10529 N12:26/13 429 VSD_LS.Alarms[2].13 PRI VSD FAULT: RUN SIGNAL
10530 N12:26/14 430 VSD_LS.Alarms[2].14 PRI VSD FAULT: INTERLOCK FAULT
10531 N12:26/15 431 VSD_LS.Alarms[2].15 PRI VSD FAULT: GATE DRIVER CML
10532 N12:27/0 432 VSD_LS.Alarms[3].0 PRI VSD Read Fail
10533 N12:27/1 433 VSD_LS.Alarms[3].1 PRI VSD Write Fail
10534 N12:27/2 434 VSD_LS.Alarms[3].2 PRI VSD Read TRIP
10535 N12:27/3 435 VSD_LS.Alarms[3].3 PRI VSD FAULT: W3 B3
10536 N12:27/4 436 VSD_LS.Alarms[3].4 PRI VSD FAULT: W3 B4
10537 N12:27/5 437 VSD_LS.Alarms[3].5 PRI VSD FAULT: W3 B5
10538 N12:27/6 438 VSD_LS.Alarms[3].6 PRI VSD FAULT: W3 B6
10539 N12:27/7 439 VSD_LS.Alarms[3].7 PRI VSD FAULT: W3 B7
