General Information - 13
150, 175 Models
Displacement 158 cu. in. (2589 cc)
Engine Type Two-Cycle, 60° V, 6 Cylinder
Loop-Charged
Full Throttle Operating Range 4500 to 5500 RPM
Power
(1)
150 – 150 HP (112 kw) @ 5000 RPM
175 – 175 HP (131 kw) @ 5000 RPM
Idle RPM in Gear
(2)
650 ± 50
Ignition Timing –Idle
(2)
W.O.T.
6° ± 2°
20° ± 1°
Emission Control System:
per SAE J1930
(2)
EM (Engine Modification)
Fuel Requirements
(2)
87 Pump Posted AKI (90 RON) – Refer to Fuel and Oil
Oil Supplied by oil injection system
Warning Signals Engine Overheat, Low Oil, No Oil, Fuel Restriction
Ignition Features
QuikStart™
and
S.L.O.W.™
Battery, Minimum 500 CCA (620 MCA)
OR 60 amp-hour, 12 volt
Spark Plug
(2)(3)
Torque
Refer to ECI Labels
18 to 21 ft. lbs. (24 to 28 N·m)
Fuses P/N 514021
Fuel Filter P/N 433190
Alternator 35-Amp, Fully Regulated
Gearcase – Lubricant
Capacity
Evinrude/Johnson Ultra-HPF™
gearcase lubricant
44 fl. oz. (1300 ml) Standard Rotation
Pwr. Trim/Tilt – Fluid Capacity 21 fl. oz. (622 ml)
Propeller
(4)
Refer to Propeller Selection
Fuel Tank
(4)
Capacity – 6 U.S. gallons (22.7 liters)
Weight
(5)
L Models – 387 lbs. (176 kg)
X Models – 407 lbs. (185 kg)
Sound at Driver’s Ear
(LpA) ICOMIA 39.94
78.2 dB(A)
Transom Height L Models – 19 1/2 to 20 in. (495 to 508 mm)
X Models – 24 1/2 to 25 in. (622 to 635 mm)
(1) Rated following the standards of ICOMIA 28.83, ISO 3046, and NMMA.
(2) Emission Control Information.
(3) Any other spark plug will cause ignition problems.
(4) Not supplied in all marketing areas.
(5) Does not include propeller or fuel.
