55
A
4
2
3
A Tire del CABLE DE LA BASE (3) desde el
bastidor de la base de la caminadora. Conecte
el CABLE DE LA CONSOLA (3) del BASTIDOR
PRINCIPAL (2) al CABLE DE LA CONSOLA (3)
abajo del POSTE DERECHO DE LA CONSOLA
(4). El otro extremo del CABLE DE LA CONSOLA
debe ubicarse en la parte superior del poste.
B Abra la BOLSA DE TORNILLERÍA PARA EL
PASO 2.
C Adjunte el POSTE DERECHO DE LA CONSOLA
(4) al BASTIDOR PRINCIPAL (2) con los 3
PERNOS (A).
TORNILLERÍA PARA EL PASO 2
PIEZA TIPO DESCRIPCIÓN CANT.
A TORNILLO BRISTOL M8X1,25PX60L 3
ENSAMBLAJE PASO 2
NOTA: Tenga cuidado de no pellizcar el cable
de la consola mientras conecta el poste
derecho de la consola.
