Joie duallo - Booster Installation and Use; Latch System Installation and Removal; Securing the Child with Seatbelt

9 10
Use Booster
see images
17
-
21
!
Pull the vehicle safety belt and pass through the belt path
17
, and then buckle it up.
17
-3
3. Line up the latch connectors
with the latch anchor points,
and then click both latch
connectors into the latch
anchor points.
12
!
Make sure that both latch
connectors are securely
attached to their latch anchor
points. The colors of the
indicators on the both latch
connectors should be
completely green.
12
-1
!
Check to make sure the
booster is securely installed
by pulling on the both latch
connectors.
4. To remove the booster:
a. Press the secondary lock
button
13
-1
first and then
the button
13
-2
on the latch
connectors before removing
the booster from the vehicle
seat.
b. Rotate the latch connectors
by 180 degrees, then press
the latch adjusting button to
fold the latch connectors.
14
2
1
1
3
3
1
12
14
15
16
13
1
2
