9
10
Proper Position of the Shoulder Harness Staps
Please choose the proper pair of
shoulder harness slots according
to the height of the child.
!
The shoulder harness slots
should be at/or slightly below
the child's shoulder. Shoulder
harness straps that are too high
or too low are not safe.
5
!
If the shoulder harness straps
are not at the proper height, the
child may be ejected from the
child restraint during a crash.
Reference age newborn - 4 years old
Seat position Position 4: (with top blue diamond and
bottom blue diamond aligned)
4
!
Always install the child restraint
on the vehicle seat first, and
then place the child in the child
restraint.
Installation for
Rearward-Facing Mode
(for child under 18kg/Group 0+/1)
see images
4
-
26
see images
5
4
6
Use of Inner Cushions
1. Pull the head support aside and
thread the shoulder harness
straps through the head support
slot to fasten the head support
onto shoulder harness straps.
7
Before assembling the head
support, please check whether
the shoulder harness straps are
at the proper height. Please
refer to Proper Position of the
Shoulder Harness Straps &
Shoulder Harness Height
Adjustment.
2. While pulling up on the
webbing adjuster, pull out the
shoulder harness straps to
proper length.
8
8
- 1 Webbing adjuster
1. Inner cushions include head
support and infant body support.
2. Head support is suitable for child
in all installation modes.
3. Infant body support is for child's
protection. A child 0-6 months
must use infant body support.
Note
see images
6
-
11
7
8
1
5
