13 14
2. Squeeze the head support
adjustment lever
16
, meanwhile
pull up or push down on the head
support until it snaps into one of
the 6 positions. The head support
positions are shown as
17
.
16
17
1
2
Using in the Rear Facing Mode
(Rearward Facing Mode/for Child under 18kg
/infant - 4 years old)
see images
3
-
9
! Please install the child restraint on
the rear vehicle seat, and then put
the child in the child restraint.
see images
18
-
27
1. Press the ISOFIX adjuster button
18
-1 and pull the base back from
the vehicle seat.
2. Press the rotating button to rotate
for easier side loading/unloading
of the child, then rotate back to
desired direction.
19
&
21
3. If a tighter install or increased
cabin space is required, then
press the ISOFIX adjuster button
20
-1 and push to adjust.
20
-2
! The ISOFIX connectors must be
attached and locked onto the
ISOFIX anchor points.
21
-1
! The load leg must be installed
correctly with green indicator.
21
-2
Securing Child
After the child is placed into the
seat, check whether the Shoulder
Harness Straps are at proper height.
1. Press the webbing adjustment
button, while pulling out the
shoulder harnesses to the proper
length.
22
19
22
21
2
1
18
1
2
20
1
2
