3
电源安装在电源支架上,
装回机箱固定
Install PSU on PSU rack, then
install into the case and fix it
①
Screw pass through rubber gasket and fix into SSD Slide into calabash holes to fix it
螺丝穿过胶圈固定在SSD上
①
滑入葫芦孔固定②
Install PSU
安装电源
Install SSD安装SSD
装回电源罩
Install PSU cover
②
