JONSBO D32 PRO - Page 2

D32 PRO Tech Specs
KEY SPECS
DIMENSIONS(w/o feet and other protrusions): 384mm x 207mm x 302mm (depth/width/height)
DIMENSIONS(with feet and other protrusions): 396mm x 207mm x 314mm (depth/width/height)
Motherboard Suppo: Mini-ITX / Micro-ATX (Regular) / Micro-ATX (Back-Connect, the chassis needs to be
switched to B mode)
Expansion Slots: 4
Weight1 (PRO): N.W. 4.6kg / G.W. 5.8kg
Weight2 (PRO/MESH): N.W. 4.3kg / G.W. 5.5kg
COMPATIBILITY & CLEARANCE
CPU Air Cooler Clearance:
In A mode, the height limit is 170mm (Intel CPU) or 169mm (AMD CPU)
In B mode, the height limit is 164mm (Intel CPU) or 163mm (AMD CPU)
*For details on A/B mode, please refer to page 5~8
Radiator Clearance: Top, up to 240
GPU Clearance: Up to 365mm
ATX PS2 PSU Clearance:
•When the GPU is installed in the rst PCI-E slot of the chassis, the maximum
length of the power supply is 150mm, and the recommended length is ≤140mm
•When the GPU is installed in the second PCI-E slot of the chassis, the maximum
length of the power supply is 170mm, and the recommended length is ≤160mm
*This mounting position depends on the motherboard, please refer to the motherboard specications
•When the GPU length is ≤288mm and the power compament paition is removed, the power supply
length is limited to 200mm (not compatible with 16A plugs)
SFX PSU Suppo: SFX / SFX-L
FRONT I/O PORTS
USB 3.2 Gen 1 Type-A: 2
USB 3.2 Gen 2 Type-C: 1
Headset Audio Jack: 1
FAN SUPPORT
Top: 2 x 120mm / 2 x 140mm
Rear: 1 x 120mm
Bottom: 3 x 120mm / 2 x 140mm, depends on other hardware congurations
DRIVE BAYS
2.5": up to 4, depends on other hardware congurations
3.5": up to 2 (shared with the 2 x 2.5" mounts), depends on other
hardware congurations
