C
Contents
INTRODUCTION............................................................ 5
SAFETY......................
....................................................6
ASSEMBLY........................................
............................ 8
OPERATION...............................................................
....9
MAINTENANCE............................................................10
TECHNICAL DATA.........
..............................................12
EMISSION CONTROL WARRANTY STATEMENT..... 13
INTRODUCTION
Operator's manual
The initial language of this operator's manual is English.
Operator's manuals in other languages are translations
from English.
Overview
(Fig 1. )
1. Shoulder strap (BV2126)
2. Throttle trigger
3. STOP switch
4. Speed control
5. Fan housing
6. Fuel Tank Cap
7. Air filter
8. Choke
9. Primer bulb
10. Inlet cover
11. Vacuum handle (BV2126)
12. Cutters (BV2126)
13. Fan impeller
14. Standard nozzle
15. High velocity nozzle
16. Blower tube
17. Tube clamp bolt
18. Tube clamp nut
19. Muffler
20. Ground wire
21. Starter handle
22. Starter device
23. Carburetor adjustment screws
24. Operator's manual
25. Vacuum device with collection components that
consists of items 26-30 below
26. Collection bag tube
27. Collection bag
28. Vaccum tube in two sections
29. Screw
30. Shoulder strap
Chemical warning
(Fig 2. )
Symbols on the product
(Fig 3. ) Warning
(Fig 4. ) Read this manual
(Fig 5. ) Use approved hearing protection
(Fig 6. ) Use approved eye protection
(Fig 7. ) Use approved dust mask
(Fig 8. ) Use approved protective gloves
(Fig 9. )
The product can cause objects to eject,
which can cause damage to the eyes
(Fig 10. ) Do not go near the impeller as it turns
(Fig 11. ) Do not let a child near the product
(Fig 12. )
Make sure that long hair is put up above
your shoulders
(Fig 13. ) Safe distance
Note:
Other symbols/decals on the product refer to
certification requirements for other commercial areas.
Product liability
As referred to in the product liability laws, we are not
liable for damages that our product causes if:
• the product is incorrectly repaired.
• the product is repaired with parts that are not from
the manufacturer or not approved by the
manufacturer.
• the product has an accessory that is not from the
manufacturer or not approved by the manufacturer.
• the product is not repaired at an approved service
center or by an approved authority.
238 - 001 - 06.07.2017
5
