Jonsered BV32 - Vacuum Bag Assembly; Vacuum Tube Assembly

PARTS LIST NO.
PAGE NO.
REPLACES
PARTS LIST
MODEL:
BV32
530068885 -- 8/07/02
Note: Illustrations may differ from actual models due to design changes
4
530068885--9/13/01
60 530010960 Assy--Connecting Rod
61 530069232 Kit--Rope
62 530032103 Inner Bearing
63 530015787 Ring--Retaining (Crankcase)
64 530019158 Seal--Crankshaft
65 530032102 Outer Bearing
66 530015789 Ring--Retaining (Crankshaft)
67 530014016 Assy--Crankcase
68 530039189 Assy--Flywheel
(Incl. #70)
69 530347987 Washer
70 530023817 Spring--Starter Dog
71 530038386 Spacer--Flywheel
72 530014156 Assy--Crankcase/Crankshaft
(Incl. #58 & 62--67)
73 530016080 Screw
74 530015496 Screw
75 530027523 Retainer
76 530069486 Kit--Starter Pulley (Incl. #73)
77 530042085 Spring--Starter
78 530069714 Kit--Fan Housing
(Incl. #61, 71, 73--77, 79 & 86)
79 530027569 Handle--Starter
80 530069247 Kit--Line
81 530015769 Screw
82 530015815 Screw
83 530015672 Spring--Torsion (Left)
84 530069348 Kit--Spark Arrestor
85 530019167 ”O” Ring--Seal
86 530029182 Eyelet--Flange
87 530015647 Pin--Pivot
88 530049185 Sponge--Air Dam
89 530029119 Tube--Rope Retainer
90 530094710 Blower Housing (Upper)
91 530029173 Band--Blower Hsg.
92 530014157 Assy--Impeller (Incl. Hub)
93 530015667 Spring--Torsion (Right)
94 530047700 Inlet Door
95 530015441 Washer--Conical
96 530016320 Nut
97 530047736 Blower Housing (Lower)
(Incl. #82, 83, 87, 93 & 94)
98 530069692 Kit--Muffler Guard
99 530038508 Assy--Nozzle & Tube
100 530015818 Washer--Impeller
101 530019253 Seal Foam
102 530019168 Grommet
103 530069294 Kit--Gasket (Incl. #35, 49, 50 & 54)
-------- Operator’s Manual
530088113 (Scan)
530088114 (Euro)
530047885 Decal--Door Instruction
Description
Key
No.
Part
No.
Description
Key
No.
Part
No.
1 530069863 Kit--Handle
2 530026994 Isolator
3 530029111 Spacer--Isolator
4 530015635 Screw
5 530029130 Isolator--Handle (Rear)
6 530015813 Screw
7 530029072 Trigger
8 530027597 Spring--Lever Return
9 530015702 ”C” Clip--Throttle Lock
10 530029117 Throttle Lock Button
11 530015840 Pin--Handle
12 530024772 Spring--Throttle
13 530056005 Shroud--Left
14 530056006 Shroud--Right
15 530053346 Heat Shield--Air Dam
16 530069572 Kit--Switch
17 530029129 Isolator--Engine Mount
18 530029295 Isolator Tank
19 530015814 Screw
20 530014162 Assy--Fuel Tank
(Incl. #21, 22 & 80)
21 530014347 Assy--Fuel Cap w/retainer
22 530095646 Assy--Fuel Pick--up
23 530014160 Assy--Handle Cover
(Incl. #9, 10 & 12)
24 530054877 Cover--Filter
25 530029112 Filter--Air (Foam)
26 530029404 Baffle--Air
27 530069293 Kit--Muffler
28 530029116 Spring--Muffler
29 952030201 Spark Plug (RCJ--8Y)
30 530001624 Screw
31 530071581 Kit--Cylinder
32 530029425 Wire--Lead (Switch)
33 530039137 Ignition Module
34 530016357 Screw
35 530019178 Gasket--Cylinder
36 530025875 Ring--Piston
37 530069277 Kit--Piston (Incl. #36,38,& Pin)
38 530015162 Retainer
39 530015306 Screw
40 530029426 Wire--Ground (Switch)
41 530015849 Screw
42 530015254 Washer
43 530015852 Spacer--Choke
44 530029114 Choke Shutter
45 530015775 Screw
46 530037492 Assy--Cable
47 530029115 Plate--Air Filter Mtg.
48 530069644 Kit--Carburetor Ass’y.
(WT 141A w/ Limiter Cap)
49 530019164 Gasket--Carb
50 530019165 Seal--Foam/Reed Block
51 530015771 Screw
52 530029113 Ground Wire (Static)
53 530047696 Reed Block/Heat Shield
54 530019166 Gasket--Reed Block/C’case
55 530027593 Reed Valve
56 530027594 Reed Stop
57 530016064 Screw
58 530014033 Assy--Crankshaft
59 530015126 Key--Flywheel
Not Shown
L
= REFER TO THE SERVICE REFERENCE INDICATED FOR MORE INFORMATION.(LOCATED AT END OF IPL)
=
NEW PART NUMBER FOR THIS IPL
