Place each Solo and Mini face down on a scratch-
free surface and align, as shown in Figure A.
STEP 1
Locate three connection bars and place them on the
Solos and Minis, as shown in Figure A. Attach
connection bars using (12) M4x8mm Allen screws
and hand tighten using the included Allen wrench.
STEP 2
Your Joovv system comes with extra screws.
Do not use a drill to install the screws as this can
strip the threads.
#1 Lead Mode #2 Follow Mode
#4 Follow Mode#3 Follow Mode
FIG. A
Door Mount
(2 people required)
SETTING UP YOUR JOOVV MAX
6.2
