With assistance from another person, hold the pair
of Solos (#1 and #2) in place. With your free hand
connect the snap links to the door hooks, as shown
in Figure F.
Be sure to adequately support the devices while
connecting them to the door hooks.
STEP 7
With assistance from another person connect the
pair of Minis to the pair of Solos by lining up the
threaded posts with the slots on the bottom ends of
Solo #1 and #2. Then, lift up and insert threaded
posts on the top ends of Mini #3 and #4. Once
inserted, slide forward to lock in place and release,
as shown in Figure G.
STEP 8
#1 Lead Mode#2 Follow Mode
#3 Follow Mode#4 Follow Mode
FIG. G
Door Mount
(2 people required)
SETTING UP YOUR JOOVV MAX
6.6
