With assistance from another person, hold the pair
of Solos (devices #1 and #2) in place. With your free
hand connect the snap links to the door hooks, as
shown in Figure F.
Be sure to adequately support the devices while
connecting them to the door hooks.
STEP 7
With assistance from another person connect the
second set of Solos by lining up the threaded posts
with the slots on the bottom ends of Solos #1 and
#2. Then, lift up and insert threaded posts on the top
ends of Solos #3 and #4. Once inserted, slide
forward to lock in place and release, as shown in
Figure G.
STEP 8
#1 Lead Mode#2 Follow Mode
#3 Follow Mode#4 Follow Mode
FIG. G
Door Mount
(2 people required)
SETTING UP YOUR JOOVV QUAD
7.6
