User and Service manual JO960
Ver. 2.0
Ver. 1.1 8
To access the cooling unit turn open the knob (6 on figure 2) and
carefully lift the electronic part (upper painted red) lift it to upright
position.
1. Water tank contains 40 litre cooling media.
2. Filling hole
3. Thermostat
4. Condensor
5. High pressure pressostat
6. Opening knob
Figure 2: Cooling unit
2
1
3
4
5
6
