5
ENGLISH
Fig. 1b
X
Y
Jøtul F 476
900053-P03
Min 2180
564
155
1025
1180
554
230
180
160
230
* Semi-insulated chimney / shielded flue pipe
500
782
604
374
50
200
200
440
440
622
852
*
*
*
100
424
654
Hole in floor for external air supply
Ø 100mm connection
Jøtul F471, F476
Min. measure floorplate
X/Y = Acc. to national standards
and regulations.
Combustible ceiling
Combustible wall
Min. distance to combustible wall
1000
1000
