Jøtul FS 350 - Page 18

18
Combustible wall
Long legs 9 tracks shall be visible
Short legs 9 tracks shall be visible
ca 15 mm
ca 15 mm
900080-P02
609
391
375
430
y
257
300
658
40
Min. mål gulvplate / measurement floorplate x/y=Acc. to national regulatives and regulations
x
1300
Radiation zone
Measurements according to EN 13240
Norge: x=520 ; y=300 Danmark: x=820 ; y=300 Sverige: x=720 ; y=300
217217
684
1587
1587
1587
1791
396
496
715
Ø170
217
ca 558
ca 270
Jøtul FS 350 - I 350
Fig. 1
Product: Jøtul FS 350 - I 350
