JOYEE M800 - Page 21

21
PEGASUS / TYPICAL / JOYEE
M
G
The diagram of tube and valve connection
※氣閥軟管接管圖
流量塞頭
plug of air-
control
A
B
B
C
C
E
E
D
D
G
F
F
H
I
H
K
L
L
流量塞頭
plug of air-
control
流量塞頭
A
黑色Black
8x5-800
∅
B
藍色Blue
6x4-700
∅
C
桔色Orange
6x4-700
∅
D
藍色Blue
4x2.5-800
∅
E
桔色Orange
4x2.5-800
∅
F
透明Clear
4x2.5-900
∅
G
黑色Black
4x2.5-1000
∅
H
透明Clear
4x2.5-1000
∅
I
螺紋軟管Threaded hose
11x8-400*1
∅
黑色Black
6x4-600
∅
K
黑色Black
6x4-600
∅
L
螺紋軟管Threaded hose
∅
3分半x1.5-750
J
A
K
J
J
M
M
黑色Black
4x2.5-1000
∅
