JOYEE M800 - Page 38

38
4
3
1
7
1
2
6
AST-11
1
名 稱
Description
單位用量
Amt.Req.
序 號
Ref.No.
物料編號
Part.No.
壓腳汽缸座
CR-06 1
壓腳汽缸 Foot lifter cylinder
1
VG2700A-DVC09
1
塑膠接頭 Plastic connector
6
SW0704
2
盤型墊片 Dish washer M6
SW0161
2
內六角螺絲 Inner hexagon screw
1
VG2700A-DVC07-2
空氣管接頭(藍色)
-
4
3 VG2700A-DVC07-1
空氣管接頭(桔色)
-
Air connector (Orange)
Air connector (Blue)
壓腳汽缸零件分析表
The section list of foot lifter cylinder
2
1
7
5
M6x12
SDA 20x32
20x19
-
5
AST-11-9
1
Foot lifter cylinder bracket -
AST-11-8 1
壓腳汽缸座
Foot lifter cylinder bracket -
壓腳汽缸座
M700、GN2000
7
EX5214、JY-B804、JY-B805
7
9
8
8
9
Tube-02-1-700
1
氣閥軟管(桔色) Valves hose(Orange) 6x4-700mm
∅
Tube-02-2-700 1
氣閥軟管(藍色) Valves hose(Blue) 6x4-700mm
∅
10
SW0627 1
螺帽 Nut -
10
PEGASUS / TYPICAL / JOYEE
MX5204
M800
Foot lifter cylinder bracket
GN2000
M700
EX5214
GN2000
M700
JY-B804
JY-B805
EX5214
JY-B804
JY-B805
M952
MX5204
M800
M952
