JOYEE M800 - Page 55

55
PEGASUS / TYPICAL / JOYEE
1
3
2
AST-18
風管夾 Tube clip -
1
SW0502
無頭螺絲 Headless screw M3x3
2
名 稱
Description
單位用量
Amt.Req.
序 號
Ref.No.
物料編號
Part.No.
風管座組-零件分析表
The section list of air-tube unit
3
AST-17
風管座 Tube bracket -
AST-17-8
風管座 Tube bracket -
1
AST-17-2 風管座
-
1
M800
M700、GN2000
MX5204、EX5214、JY-B804、JY-B805
3
3
1
1
1
4
5
6
DVC-05-1
流量塞頭 Plug of air-control -
4 1
Tube-01-3-1000
氣閥軟管(透明) Valves hose(Clear) 4x2.5-1000mm
∅
5
1
Tube-07
塑膠螺紋軟管 Plastic threaded hose 11x8-400mm
∅
6 1
7
7
SW0935
一般螺絲 Normal screw M4x8
1
MX5204、EX5214
GN2000
M700
JY-B804、JYB805
Tube bracket
M800、M952
GN2000
M700
M800、M952
MX5204、EX5214
JY-B804、JYB805
