PARTS LIST
Description
Sketch
QTY
4 pcs
4 pcs
2 pcs
2 pcs
2 pcs
1 pc
1 pc
1 pc
6 pcs
6 pcs
3 pcs
1 pcs
2 pcs
2 pcs
2 pcs
2 pcs
2 pcs
2 pcs
Base Cover
Base
Triangular
Connector 1
Triangular
Connector 2
Triangular
Connector
Big Roof Beam 1
Big Roof Beam 2
Roof Beam
Connector 1
Big Roof Middle
Beam
Middle Beam
Lower Connector
Support Tube 1
Hook
Big Roof Lower
Tube 1
Big Roof Lower
Tube 2
Big Roof Lower
Tube 3
Big Roof Lower
Tube 4
Big Roof Side
Tube 1
Big Roof Side
Tube 2
