4. Operation 13
Cancelling Menu [CLR]
This key uses with menu functions.
When it keeps pressing the key while printing, the printer is canceled printing.
Stopping Buzzer [ACK]
The buzzer sound stops when the key is pressed after the alarm generated, and the alarm is displayed
on the screen. However, it keeps outputting the relay contact output while phenomenon is continuing.
One key pressing deals with one alarm generation factor. And, it deals with the generation of all alarm
factor under pressing about three seconds.
Up and Down Key Cursor [CURSOR]
When it is a standard mode
When the key is pressed, the depth cursor is moved to shallow one and it moves accelerating
when keeping pressing it.
When the key is pressed, the depth cursor is moved to the deep end and it moves accelerating
when keeping pressing.
Depth at the cursor position is displayed on the depth cursor.
The cursor display is set by CURSOR" menu. (Refer to 4.3 Display Setting.)
The depth of the depth cursor doesn't display below the decimal point at 100m or more.
The depth cursor disappears when the range is switched, and the depth cursor exceeds the display
range. However, when either key is pressed, the depth cursor is displayed the under the depth scale
again.
When it is a history mode
Whenever the key is pressed, the drawing time of the history is lengthened. (four stages of 3hrψ
6hrψ12hrψ24hr)
Whenever the key is pressed, the drawing time of the history is shortened. (four stages of 24hrψ
12hrψ6hrψ3hr)
When menu is displayed
When the key is pressed, the item above the menu is selected or a set value is changed.
When the key is pressed, the item under the menu is selected or a set value is changed.
To Next Page
