JMA-7100 Instruction Manual > 3.BASIC OPERATION > 3.8 APPLIED OPERATIONS
3－107
3
3.8.8.3 Depth Graph Setting
• The Depth Graph Setting menu will appear.
[1] Depth Graph Display
• Determine whether to display received water depth information with a graph.
• One of two digital information areas is used to display data.
• When the water-depth graph is displayed, the sizes of the target tracking (TT)/
AIS numeric data display areas are exclusively decreased.
• Left-click the button located at thelower righit of the display. The
water-depth graph display function is switched between On and Off.
[2] Depth Range
• Select the depth range on the water depth graph.
[3] Time Range
• Select the time range on the water depth graph.
: Does not display a water depth graph.
: Displays the water depth graph in digital information area 1.
: Displays the water depth graph in digital information area 2.
: Sets 50 m as the depth range.
: Sets 100 m as the depth range.
: Sets 250 m as the depth range.
: Uses the depth range in the DPT sentence included in
received data.
: Sets 10 minutes as the time range.
: Sets 15 minutes as the time range.
: Sets 30 minutes as the time range.
: Sets 60 minutes as the time range.
: Sets 12 hours as the time range.
Target
Off
Area1
Area2
50m
100m
250m
AUTO
10min
15min
30min
60min
12hour
To Next Page
