9.2.2 C-MAP cartridge information
Cartridge information of C-MAP can be displayed.
[Operation procedure]
Open the Cartridge Information screen by performing the following menu operations.
[Menu] button → Chart → Cartridge Information
9.2.2.1 Contents of C-MAP cartridge information
The following contents are displayed on the “Cartridge Information” screen.
Display item
Display contents
Cartridge Code Displays the cartridge code.
For the details, refer to “9.2.2.2 Cartridge code”.
Description
Displays the name of the cartridge.
Geographical Area Displays the geographical area that is defined by the area code.
For the details, refer to “9.2.2.3 Area code”.
Cartridge Type Displays the cartridge type.
One of the following types is displayed: Marine / Terrestrial / Aeronautical /
Submarine / Inland Waters / Road
Release Date Displays the release date.
The information expires one year after the date of release and an expiration
warning screen is displayed. Read the contents of the warning carefully and
click on the [OK] button. The system assumes that consent has been made
and closes the screen.
Release Version
Displays the release version.
9.2.2.2 Cartridge code
The cartridge code that is contained in the C-MAP cartridge information is displayed in the format of
“XX-Yxxx-yy”.
The meaning of each field is as follows.
Field
Contents
XX
Area code (for the details, refer to 9.2.2.3 Area code.)
Y
Generation ID
xxx
Serial number
yy
Data version
