Section 13 Setting up the Operation Mode 13-2
13.2 Setting Radar Signal Processing
Set various processing methods of radar signals.
[Operation procedure]
Open the radar signal processing setting screen by performing the following menu operations.
[Menu] button → Settings → Signal Process
Setting Item Description of Setting Setting Value
Video Latitude Set up the gradation of the radar video. Narrow / Normal /
Wide / Super Wide
Video Noise Rejection Set up to remove noise and signals which are
considered to be clutters of radar video.
Off / Level1 (Low)/
Level2 (High)
AUTO Dynamic Range
Control
When this is selected, the dynamic range is
automatically adjusted.
To enable: Select.
To disable: Clear.
Process Switch Specify a particular area and set up a mode for
performing video processing on the inside and
outside of the particular area.
Off / Range Fix /
AUTO
2nd Process Mode
Set up a processing mode used in the outside of
the particular area.
This item is enabled when an option other than
[Off] is selected in the [Process Switch] combo
box.
PROC Off
3Scan CORREL
4Scan CORREL
5Scan CORREL
Remain
Peak Hold
Bird
Process Switch Range Set up the boundary range of a particular area.
This item is enabled when [Range Fix] is selected
in the [Process Switch] combo box.
0.1 to 25.5 NM
Fast Target Detection When this item is enabled, high-speed moving
targets that are suppressed by the scan
correlation processing can be detected more
easily.
To enable: Select.
To disable: Clear.
SART If it is enabled, the Radar Transponder (SART:
Search and Rescue Radar Transponder) screen
can be displayed.
This item is valid on the RADAR screen only.
To enable: Select.
To disable: Clear.
To Next Page
