3-116
3.16.5.3 Setting of EPADR Transmission Data
EPADR transmission data can be set by following procedure. However, there is a possibility that
trouble of operation using EPADR occur by setting of EPADR transmission data.
Step Operation IME/DTE response
1
• Hold down Alt key and press U
key on Main menu.
• "Set up" window is displayed.
2
• Move the cursor to "EPADR
informAtion" and press Enter
key.
• "EPADR Information" window is displayed.
3
• Move the cursor to "EPADR Tx
Data" and press Enter key.
• "EPADR Tx Data" window is displayed.
4
• When you want to send position
data, move the cursor to
"posItion" and press Enter key,
and move the cursor to "oN" and
press Enter key.
5
• When you want to send other data,
move the cursor to "File name"
and press Enter key, and select
file.
• Warning message window is displayed when the data
capacity exceeds 39 bytes.
To Next Page
