JRC jue-87 - Parts for Installation (Prepared by Shipyard); Required Tools

2-6
Table 2.1.3d Supplied Cables by JRC for IME Installation
No. Name Type Q’ty Remarks Application
1 EXT PSU Cable (IME to EXT PSU) 7ZCSC0320 1
2
Printer Signal Cable
(Printer to IME)
7ZCSC0321 1
3
Printer Power Cable
(Printer to IME)
7ZCSC0322 1
4 JB1 Cable (JB1 to IME) 7ZCSC0314 1 0.4m On stand
5 JB1 Cable (JB1 to IME) 7ZCSC0324 1
2.0m
(Option)
On wall
6 JB2 Cable (JB2 to IME) 7ZCSC0325 1
5m
(Option)
7 DTE Signal Cable (DTE to IME) 7ZCSC0203A 1 Option
8
DTE Power Cable
(DTE to Ext PUS)
7ZCSC0204 1 Option
2.1.4 Parts for Installation (Prepared by Shipyard)
Table 2.1.4 Required cables
No. Part Description Q’ty Remarks Application
1 PVC tape Vinyl tape
1
L = 15m For protecting cable
2 Copper plate JIS H 3100 1
W = 30mm,
t = 0.2mm
For grounding EME
3 Pole 1 For mounting EME
2.1.5 Required Tools
Table 2.1.5 Required Tools
No. Tool Description
1 Open-ended spanner Nominal 13 (for M8)
2 Plus screwdriver
