4-79
4.12.2 Measuring the Trip Distance and Time (Navigation Assistance 2)
· Navigation Assistance 2 shows the time when measurement started, the time measurement
ended, the total time, the average speed during measurement, and the distance over ground. If
the speed through water is input from external equipment, the speed through water is also
displayed.
· When measurement is started, the time that measurement was started is displayed, and the
total time, the average speed and total distance will gradually increase.
· When measurement is stopped, the time that measurement was stopped is displayed, as well
as the total time and distance.
· To start measurement, start measurement from the Navigation Assistance 2 screen.
· Stop measurement from the Navigation Assistance 2 screen.
Navigation Assistance 2 Screen
(Refer to "3.1.9 Navigation Assistance Screen" for screen details)
(1) Starting Measurement
1. Press
several times to display the Navigation Assistance screen.
2. Press several times to display the Navigation Assistance 2 screen.
3. The cursor will move to the "SOG NAV START/END", so press
to start measurement
of distance over ground.
4. Pressing
will cause the cursor to move to "STW NAV START/END", so press to
start measurement of distance through water.
(2) Ending Measurement
1. Press
several times to display the Navigation Assistance screen.
2. Press several times to display the Navigation Assistance 2 screen.
3. The cursor will move to "SOG NAV START/END", so press to end measurement of distance
over ground.
4. Pressing
will cause the cursor to move to "STW NAV START/END", so press to
end measurement of distance through water.
· In order to perform distance through water, speed through water must be input from
externally connected equipment.
Memo
