43
Section 3 Operation
No. ITEMS Displaying symbols
q OWN SHIP ICON Selected own ship ICON.
w SHIP POSITION Ship position is available when used with GPS/
DGPS sensors or NMEA0183 format data is
received.
e COURSE & SPEED COG (the ship’s course over the ground) and
SOG (the ship’s speed over the ground) appears.
r GPS STATUS DGPS : Differential GPS fix.
DGPS-W : Differential GPS fix (WAAS TYPE)
GPS : GPS fix.
NO FIX : Fix not available or invalid.
NO DATA : No position data input.
(NO GPS/DGPS sensor connected)
t
RANGE SCALE & RANGE RING INTERVAL
Used range scale and range ring interval.
y VIDEO PROCESS Radar video processing type.
OFF : No process. (No title display)
PROC1 : Processing type 1.
PROC2 : Processing type 2.
PROC3 : Processing type 3.
u TRAIL INTERVAL Trail interval and condition.
OFF : No trail. (no title display)
0.5 - 6 : Trail interval. (Unit: min)
CONT : Continuous trail.
i TARGET EXPANDER Target expander.
OFF : No expansion. (No title display)
ON : Target expansion.
o INTERFERENCE REJECTION Radar interference rejection. (IR)
OFF : IR off. (No title display)
ON : IR on.
!0 BEARING MODE Azimuth stabilization mode with symbol.
HUP : Head up.
NUP : North up.
CUP : Course up.
(NUP and CUP mode needs heading data)
!1 EBL & VRM Numerical display EBL and VRM.
!2 JOG-DIAL FUNCTION Selecting JOG-DIAL.
(SEA/RAIN/GAIN/TUNE/EBL/VRM)
!3 LEVEL indicator “AUTO” is displayed in automatic mode.
!4 GUARD ZONE Guard zone.
Mode : IN/OUT alarm.
Level : Threshold level.
!5 HEADING LINE Ship’s heading line.
!6 VRM VRM display. (Variable Range Marker)
!7 EBL EBL display. (Electric Bearing Line)
!8 RANGE RINGS Range ring display.
!9 DATE & TIME Month/Day Hour/Minute
@0 CURSOR INFORMATION LAT/LON of the cursor, the distance between the
vessel and the cursor, the bearing of the cursor
appear.
