MEB-3200SS, 3200RS, 3200JS, 3200CS, 3200TS (September, 2003) 3/4
LIST OF THE REPLACEMENT GAUGES
◎：Provided as standard
△：Accessory
No symbol：Optional
−：Installation is invalid.
● Throat plate ● Cloth cutting knife
● Work clamp, complete
● Work clamp
● Knife guard
● Presser support plate
● Left looper, left spreader
Part name Part No.
Application
Needle size
SRJCT
Throat plate A (standard) 320-42715 ◎◎−−− Nm90 〜Nm110
Throat plate B
(for semi-wide stitch bite) 320-42913 −−−Nm90 〜Nm110
Throat plate C (for wide stitch bite) 320-43010 −−−Nm90 〜Nm110
Throat plate D (for narrow stitch bite) 320-43218 −−−Nm90 〜Nm110
Throat plate JA (standard) 320-43424 −− −Nm120 〜Nm130
Throat plate JB
(for semi-wide stitch bite) 320-42830 −−◎ −Nm90 〜Nm110
Throat plate JC (for wide stitch bite) 320-43135 −− − Nm90 〜Nm110
Throat plate JD (standard) 320-43622 −− − Nm90 〜Nm100
Throat plate JE (standard) 320-43523 −− ◎− Nm110 〜Nm120
Throat plate JF (standard) 320-43325 −− − Nm90 〜Nm100
Throat plate TE 320-43713 −−−−◎ Nm100 〜Nm110
Part name Part No.
Application
SRJCT
Compensating work clamp,
complete S, for eyelet buttonholes
320-28458 −− ◎−
Compensating work clamp,
complete M, for eyelet buttonholes
320-28554 −−◎ −
Compensating work clamp,
complete L, for eyelet buttonholes
320-29050 −− −

Work clamp,
complete for longitudinal buttonholes
320-31064 ◎−−−
Work clamp (left)
Part name Part No.
Application
SRJCT
For eyelet buttonhole 40mm 140-10102 ◎◎
For eyelet buttonhole 32mm 140-59604
For eyelet buttonhole 22mm 140-59802
For straight buttonhole 40mm 140-13908
Compensating work clamp H, 40mm
for eyelet buttonholes
140-58903
Compensating work clamp M, 32mm
for eyelet buttonholes
320-28706 ◎
Compensating work clamp S, 24mm
for eyelet buttonholes
320-28300 ◎◎
Presser support plate (left)
Part name Part No.
Application
SRJCT
Presser support plate for eyelet buttonholes 320-27104 ◎◎−−−
Presser support plate J, M for eyelet buttonholes 320-28904 −−◎ −
Presser support plate C, S for eyelet buttonholes 320-28508 −− ◎−
Presser support plate L for eyelet buttonholes 320-29100 −− −
Presser support plate for straight buttonholes 320-29506 −−−
Presser support plate for eyelet buttonholes 140-11506 − − − − ◎
Presser support plate for straight buttonholes 140-13700 − − − −
Presser support plate (right)
Part name Part No.
Application
SRJCT
Presser support plate for eyelet buttonholes 320-27005 ◎◎−−−
Presser support plate J, M for eyelet buttonholes 320-28805 −−◎ −
Presser support plate C, S for eyelet buttonholes 320-28409 −− ◎−
Presser support plate L for eyelet buttonholes 320-29001 −− −
Presser support plate for straight buttonholes 320-29407 −−−
Presser support plate for eyelet buttonholes 140-11407 −−−−◎
Presser support plate for straight buttonholes 140-13601 −−−−
Applicable zigzag
Left looper Left spreader Application
width (mm)
Part No. Part No. S R J C T
2.0〜3.2 320-40800 320-40917 ◎◎◎◎◎
2.6〜4.0 140-30902 140-31116 −
Work clamp (right)
Part name Part No.
Application
SRJCT
For eyelet buttonhole 40mm 140-10003 ◎ ◎
For eyelet buttonhole 32mm 140-59505
For eyelet buttonhole 22mm 140-59703
For straight buttonhole 40mm 140-13909 −−
Compensating work clamp H, 40mm
for eyelet buttonholes
140-58804
Compensating work clamp M, 32mm
for eyelet buttonholes
320-28607 ◎
Compensating work clamp S, 24mm
for eyelet buttonholes
320-28201 ◎◎
J, C Type ⇒ L: Accessory for compensating work clamp L, complete,
for eyelet buttonholes (optional)
J type ⇒ S: Accessory for compensating work clamp S, complete,
for eyelet buttonholes (optional)
C Type ⇒ M: Accessory for compensating work clamp M, complete,
for eyelet buttonholes (optional)
＊For the J, C, T type, use cloth-cutting knife and knife guard that
are equal in length to the maximum sewing length or shorter.
(Maximum sewing length ⇒ S: 24mm, M: 32mm, L: 40mm)
★Standard type ⇒ Hardness of the knife guard
is high (heat-treated)
★★Hardness of the knife guard is low
(not heat-treated)
For eyelet buttonhole
Part No.
Shape (mm)
Max. cutting
Application
XY
length (mm)
SR J* C* T*
140-41206 2.9 4.4 38 ◎◎ LL−
320-63604 2.9 4.4 24 S ◎◎
320-63703 2.9 4.4 32 ◎ M
320-63802 2.1 3.2 38 −
320-63901 2.1 3.2 24
320-64008 2.1 3.2 32
320-64107 3.2 5.4 38 −
320-64206 3.2 5.4 24
320-64305 3.2 5.4 32
320-66904 2.7 5.1 38 −
For straight buttonhole
Part No.
Shape (mm)
Max. cutting
Application
XY
length (mm)
SR J* C* T*
140-41404 0 0 38
△△
−
320-65302 0 0 24
320-65401 0 0 32
For eyelet buttonhole (standard)★
Size
Part No.
Application
(mm)
SR J* C* T*

38 320-67209 △△ −
36 320-67308 −
34 320-67407 −
32 320-67506
30 320-67605
28 320-67704
26 320-67803 △
24 320-67902
22 320-68009 ◎◎◎△△
20 320-68108 △△
18 320-68207 ◎◎
16 320-68306 △△
14 320-68405
12 320-68504
10 320-68603
For eyelet buttonhole★★
Size
Part No.
Application
(mm)
SR J* C* T*
38 320-62101 −
36 320-62200 −
34 320-62309 −
32 320-62408
30 320-62507
28 320-62606
26 320-62705
24 320-62804
22 320-62903
20 320-63000
18 320-63109
16 320-63208
14 320-63307
12 320-63406
10 320-63505
For straight buttonhole
Size
Part No.
Application
(mm)
SR J* C* T*
40 140-42501 −
36 320-64404 −
34 320-64503 −
32 140-42600
30 320-64602
28 320-64701
26 140-42808
24 320-64800
22 140-42907 △△
20 320-64909
18 320-65005
16 140-43103
14 320-65104
12 320-65203
10 140-43301
Shape
X
Y
9
