LZ-2290A-SR-7 (August, 2004) 2/4
WHEN YOU PLACE ORDERS
SEWING PATTERN
LZ2290ASR7WB
SC916 SIP100D
● Machine head
● PSC box/Operation panel for SC
Model
––
AK121
––
––
––
V059
S189A
S189B
––
––
––
Part No.
400-03640
GAK-A21000B0
D1501-583-H00
D1502-583-H00
B1551-586-000
SS-7090910-SP
225-26560
MAV-059000AA
MAS-189000AA
MAS-189000AB
40017095
22591564
10064004
10061554
MAN09700BA0
SS5110710SP
HX005750000
Description
Optional switch kit
Auto-lifter (pedal-driven)
Presser bar
Presser connecting rod
Presser foot connecting foot
Screw
Hard-point hook
Tension-free feeder (Tape feeder)
Pneumatic type
Solenoid type
Thread tension disk asm.
Presser foot asm.
Feed dog
Throat plate asm.
Fagoting folder asm.
Screw
SmartMedia card 16MB
Feature
This handy switch is used to control various functions*. It is
most effective when operating the machine in a standing
position. (＊Needle up/down correction, 1-stitch correction,
reversestitch correction, auto lifter and thread trimmer, etc.)
––
The aforementioned parts are used when a lockstitching type
presser foot is installed on the machine.
The blade point of this hook prevents abrasion.
The amount of tape to be fed can be adjusted in accordance
with the sewing speed of the machine. It is adaptable to
processes for attaching reinforcement tape, attaching elastic
tape or lace to foundation.
Applies tension to desired portions of the tape fed from a
tension-free tape puller. The device is started/stopped by
operating the knee switch. This increases operator
productivity without interrupting the sewing work.
––
OPTIONS
Machine head type Code
Standard S
PSC box Code
For General Export 3-phase 200〜240V D
For General Export Single-phase 200〜240V K
For CE Single-phase 200〜240V N
Control box Code
Standard S
Operation panel Code
IP100D IP100D
Type Code
Quick reverse type R
Wiper
Push-button-type
reverse feed switch
Code
Provided Provided WB
Device / Attachment Code
Auto-lifter (pedal-driven) AK121
Not provided
Name of
pattern
Stitch pattern
Straight
stitch
Standard
zigzag
2-step
zigzag
Blind stitch
(left)
Blind stitch
(right)
Custom
pattern
3-step
zigzag
Scallop (left)
Standard Crescent Equal-width Standard Crescent Equal-widthEqual-width
Scallop (r ight)
Equal-width
Number of
stitches
1246
666633
12 2424 12
Max.500
T-shape
stitching (left)
T-shape
stitching (right)
Pattern
stitching 1
Pattern
stitching 2
(fagoting)
Pattern
stitching 3
Pattern
stitching 4
2+a
Name of
pattern
Stitch pattern
Number of
stitches
Presser foot connecting
components
(Replaceable presser bar)
Presser foot connecting
components
Elastic tape tensing
device
Dual disks
Gauge set for fagoting
