51
03.11 EN
Braking with the service brake
Procedure
• Move the tiller (7) up or down to one of the brake zones (B).
This mechanically brakes the drive motor.
Z When the tiller (7) is released it reverts to the upper braking zone (B). When the
truck is parked, the service brake acts as a parking brake.
Inversion braking
Procedure
• Turn the travel switch (3) to the opposite direction.
The truck brakes regeneratively until it starts to move in the opposite direction.
Z The brake force depends on the position of the travel switch (3).
NOTE
If the controller or drive unit fail, plugging has no effect.
Regenerative braking
Procedure
• On releasing the travel switch (3) – travel switch in neutral position – the truck
decelerates regeneratively via the coasting brake.
The truck brakes to a halt regeneratively via the coasting brake. The service brake
then applies.
CAUTION!
If the coasting brake has been switched off by the service department, only the
service and/or plugging brake can be used.
Parking brake
Z The mechanical brake (parking brake) applies when the truck comes to rest.
51
03.11 EN
Braking with the service brake
Procedure
• Move the tiller (7) up or down to one of the brake zones (B).
This mechanically brakes the drive motor.
Z When the tiller (7) is released it reverts to the upper braking zone (B). When the
truck is parked, the service brake acts as a parking brake.
Inversion braking
Procedure
• Turn the travel switch (3) to the opposite direction.
The truck brakes regeneratively until it starts to move in the opposite direction.
Z The brake force depends on the position of the travel switch (3).
NOTE
If the controller or drive unit fail, plugging has no effect.
Regenerative braking
Procedure
• On releasing the travel switch (3) – travel switch in neutral position – the truck
decelerates regeneratively via the coasting brake.
The truck brakes to a halt regeneratively via the coasting brake. The service brake
then applies.
CAUTION!
If the coasting brake has been switched off by the service department, only the
service and/or plugging brake can be used.
Parking brake
Z The mechanical brake (parking brake) applies when the truck comes to rest.
