05.10 EN
152
6.3 Unlocking the engine bonnet
Unlocking the engine bonnet
Requirements
– For trucks with a closed cab open both cabin doors
before lifting the engine cover (o).
Procedure
• Set the steering column to the parking position
((see "Adjusting the steering wheel / steering
column" on page 67)).
• Tilt the backrest forward, move the driver's seat
forward and lock it in position ((see "Adjusting the driver’s seat" on page 64)).
• Pull the lever (137) in the arrow direction (L) until the engine cover is unlocked.
The engine cover is now slightly open.
Engine cover emergency unlocking
Requirements
– The engine cover cannot be unlocked.
Procedure
• Open the floor plate by undoing the quick release
fasteners.
• Pull the cable (193) on the cover lock (192).
• Raise the engine cover until it engages in the first
stage.
L
F
137
193
192
