23
05.10 EN
3.3 Weights
Z All dimensions in kg.
3.4 Mast versions
Z All dimensions in mm
Special trucks are not included in this overview.
DFG 316s DFG 320s TFG 316s TFG 320s
Truck weight* 2800 3100 2800 3100
Axle load, w.o. load front/rear* 1340 /
1460
1350 /
1750
1330 /
1470
1340 /
1760
Axle load, w. load front/rear* 3870 / 520 4500 / 590 3860 / 530 4531 / 600
DFG/TFG 316s-320s Hydrostatic
Mast table
VDI 3596
Description
Lift h3
Free lift
h2
Height retracted
h1
Hei gh t
extended h4
Mast
weight
(kg)
ZT
2900 150 1985 3520 440
3100 150 2085 3720 450
3300 150 2185 3920 465
3600 150 2335 4220 485
3800 150 2435 4420 500
4000 150 2535 4620 525
4500 150 2835 5120 565
5000 150 3085 5620 600
ZZ
2900 1290 1940 3550 465
3100 1390 2040 3750 480
3300 1490 2140 3950 490
3600 1640 2290 4250 515
3800 1740 2390 4450 545
4000 1840 2490 4650 555
4500 2140 2790 5150 600
DZ
4200 1290 1940 4850 590
4350 1340 1990 5000 600
4500 1390 2040 5150 610
4800 1490 2140 5450 630
5000 1565 2215 5650 650
5500 1740 2390 6150 700
6000 1940 2590 6650 740
