Montageanleitung Art.-Nr. 20147
Teileliste | Part list | Liste des pces fournies | Lista delle parti:
O P Q R S T
1 x 2 x 2 x 2 x 2 x 1 x
26782 25936 26545 26135 26092 25942
A B C D E F G
~ 970 x 480 mm ~ 970 x 400 mm
Aluminium
~ 459 mm
Aluminium
~ 382 mm
~ 739 x 485 mm
~ 980 x 765 mm
1 x 1 x 1 x 1 x 2 x 1 x 2 x
52597 52596 52395 52394 52521 52204 25890
H I J K L M N
Aluminium
~ 713 mm
1 x 4 x 4 x 2 x 4 x 2 x 4 x
25937 25792 33523 22790 26398 26399 26641
Werkzeug notwendig! Required tools!
Outils nécessaires ! Gereedschap nodig!
