JVA ELECTRIC FENCE SYSTEMS
27
7.6.16 Binary Options 2 (18x#)
Each option in this table can be turned on by adding
the corresponding value.
For option+ 1 set 18 to 01, for + 1 and +2 set to 03.
+1: Enable Siren Acknowledge. The siren will chirp
once for armed and twice for disarmed.
+2: Enables a home alarm style entry/exit delay for
the gate input. See also option 13.
+4: Sets the keypad bus baud rate to 4800 (default is
2400), all units in a group, PC and Keypad must
be set to the same baud rate. The change will not
take effect until after a reset.
+8: Sets the keypad bus baud rate to 9600 (default is 2400)
Note: Z11 defaults to +1.
Note: +2, +4 and +8 were added in code version 7v92.
7.6.15 Anti-Bridging threshold (17x#)
removed from circuit, by an intruder bridging the feed to returns together and then
cutting the live wires in between.
will trigger if the Fence Voltage rises OR falls quickly by more than the threshold. A
slow change to the voltage will not trigger a Fence Alarm until the Voltage is less than
the Fence Alarm Voltage (03x#)
this level a fence (return) voltage normally reading 7.5kV will trigger a Fence Alarm if
the voltage quickly rises to over 8.3kV or falls to less than 6.7kV.
Notes:
1. Power Level (Option 1) must be set higher than the normal fence running voltage,
otherwise if the load is released (fence bridged) voltage control will limit the voltage
rise and the anti-bridging alarm would not activate. For the above example, Option
1 must be set to 7 or greater to allow the un-loaded fence to rise to 8.3kV or
higher, thus triggering the Alarm.
2. A minimum of 5% was added in code version 7.92.
Installation Programming Options
Value Function
0 None
+1 Siren codes
+2 Gate delay type
+4 4800 baud
+8 9600 baud
+16
+32
Binary Options 2 (18x#)
