JVA ELECTRIC FENCE SYSTEMS
29
7.6.19 Group Mode (26x#)
A group must have only one master. The other Energizers
in the group are slaves. Group Voltage display energizers
require each slave to have a different number. Since the
keypad bus is common among the group one keypad can
be used to program all units for all options except this Group
Mode (for obvious reasons).
The procedure is:
Energizers into a group.
NOTE: At this time groups are limited to a master and 14
slaves.
In some markets Group Mode may not be available.
For details on group wiring and operation see APPENDIX A.
Value (x) Mode
0 No Group
1 Master
2 Slave 1
3 Slave 2
4 Slave 3
5 Slave 4
6 Slave 5
7 Slave 6
etc etc
15 Slave 14
Group Mode (26x#)
Installation Programming Options
Function Logic for alarm state (opposite of normal state)
Fence x Fence x Alarm: Zone x is Armed (Pulsing) AND the Fence Return Voltage
has fallen below the Fence Alarm Voltage for more pulses than the
Missed Pulse Count. Not latched.
Fence x
alarm or off
Zone x is Off OR the Fence Return Voltage has fallen below the Fence
Alarm Voltage for more pulses than the Missed Pulse Count. Not Latched.
polar
Energizer is Armed (Pulsing) AND the Fence Return Voltages on either
pulses than the Missed Pulse Count. Not latched.
Armed x Zone x is Armed (Pulsing)
General AC Fail OR Tamper OR Low Battery OR Gate Alarm OR Internal Error.
Latched for internal errors only.
Siren Fence Alarm 1 OR Fence Alarm 2 OR Gate Or Tamper, will time out after
the Siren Time Out time. This function is latched.
Strobe As per Siren but does not time out, will remain On until both Zones are
switched off. This function is latched.
AC Fail Alarm on AC Fail
Battery Alarm on low or bad battery
Tamper Alarm when tamper circuit enabled (option 16), the lid is up, and J3 is
Group
wide x
Group relay functions are the collected status of the whole group of Z
energizers. Group Armed for example is set only if all energizers in the
group are armed.
Relay Opons Explained
