JVA ELECTRIC FENCE SYSTEMS
33
JVA Z114 LCD Keypad Features
8.3 Connecting Multiple Keypads to a system
Up to three keypads may be used to remotely monitor and control the Z series
security energizers.
ADDRESS. This is best achieved by connecting one keypad (at a time) to the Master
Energizer and updating the KEYPAD ADDRESS. Once all Keypads have a different
address, all can be connected to the system. A recommendation is that one Keypad
is kept at ADDRESS 1.
The Energizer now needs to be introduced to all of these Keypads. This is achieved
[USER PIN]*68#. Alternately the power can also be removed to reset the Energizer.
After a reset, the Energizer will determine what Keypads are connected, and only
being added to the system once it is running.
If the security system is to use a PC based interface such as Perimeter Patrol,
KEYPAD ADDRESS 2 should not be used by a keypad. The PC software uses this
address to control the Energizers.
8.4NotesRegardingKeypadConguration
Zone 1 (the master) must be connected to the group. If it is not connected the
other energizers in the group will not send status packets to the keypad. The status
packets contain voltage and alarm information which the keypad displays. If Zone 1
is not connected, the keypad will report a communications failure with all the zones.
A Slave Energizer disconnected from the Group will only talk to a Keypad if it has a
KEYPAD ADDRESS of 1. When adding/removing an energizer to/from the group, be
be connected to the group for this operation to work.
function will not work properly.
Note: If the group ID has recently been changed you may need to reset ([PIN]*68#)
before the new ID’s will be properly reported to the keypad.
