JVC CA-MXJ75R - Installation and Placement Guidelines; Proper Ventilation Requirements; Unit Placement Diagrams

Front view
Caution: Proper Ventilation
To avoid risk of electric shock and fire, and to prevent
damage, locate the apparatus as follows:
1 Front:
No obstructions and open spacing.
2 Sides/ Top/ Back:
No obstructions should be placed in the areas shown
by the dimensions below.
3 Bottom:
Place on the level surface. Maintain an adequate air
path for ventilation by placing on a stand with a height
of 10 cm or more.
CA-D3SCA-D3S
1 cm1 cm
15 cm 15 cm
15 cm 15 cm
15 cm
10 cm
CA-MXJ75R
Side view
– G-3 –
CA-MXJ75R
