9
English
7
Select the speaker to adjust the distance, then display
the pop-up window.
8
Adjust the desired speaker distance.
• For each speaker (FRONT SPEAKER, CENTER
SPEAKER, SURROUND SPEAKER), set the distance
from the listening point within the range of 0.3 m to
9.0 m in 0.3 m intervals.
9
Repeat steps
7
to
8
to adjust other speakers’ distance
if necessary.
To finish the setting
3. 0m
3. 0m
0dB
DISTANCE
CENTER SPEAKER
FRONT SPEAKER
USE TO SELECT. USE ENTER TO CONFIRM
TO EXIT, PRESS
[
SET UP
]
.
ENTER
SELECT
RETURN
SURROUND SPEAKER
3. 0m
3. 0m
Speaker Diagram
Front Speakers
Center Speaker
Surround Speakers
• The selected speaker icon is highlighted blue.
MX-JD5[UE].book Page 9 Friday, June 25, 2004 8:00 PM
