1-2 (No.YF079)
SPECIFICATION
Camcorder
AC Adapter
Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject to change without
notice.
For General Power supply DC 11.0 V(Using AC Adapter)
DC 7.2 V (Using battery pack)
Power consumption Approx. 3.2 W (LCD monitor off, viewfinder on)
Approx. 4.2 W (LCD monitor on, viewfinder off)
Dimensions (W × H × D) 56 mm × 94 mm × 112 mm
(with the LCD monitor closed and the viewfinder pushed back in)
Weight Approx. 430g
(without battery, cassette and lens cap)
Approx. 510 g
(incl. battery, cassette and lens cap)
Operating temperature 0°C to 40°C
Operating humidity 35% to 80%
Storage temperature -20°C to 50°C
Pickup 1/6" CCD
Lens F 1.8, f = 2.2 mm to 55 mm, 25:1 power zoom lens
Filter diameter Ø27 mm
LCD monitor 2.5" diagonally measured, LCD panel/TFT active matrix system
Viewfinder Electronic viewfinder with 0.16" color LCD
Speaker Monaural
For Digital Video
Camera
Format DV format (SD mode)
Signal format PAL standard
Recording/Playback
format
Video Digital component recording
Audio PCM digital recording, 32 kHz 4-channel (12-bit), 48 kHz 2-channel (16-bit)
Cassette Mini DV cassette
Tape speed SP: 18.8 mm/s, LP: 12.5 mm/s
Maximum recording time
(using 80 min. cassette)
SP: 80 min., LP: 120 min.
For Connectors AV S-Video output Y: 1.0 V (p-p), 75 ., analogue
C: 0.29 V (p-p), 75 ., analogue
Video output: 1.0 V (p-p), 75 ., analogue
Audio output: 300 mV (rms), 1 kΩ, analogue, stereo
Microphone Input Ø3.5 mm, stereo
DV Input/output 4-pin, IEEE 1394 compliant
Power requirement AC 110 V to 240 V, 50 Hz/60 Hz
Output DC 11 V, 1 A
