EN 7
GETTING STARTED
GETTING STARTED
Controls
A Stop Button [8] (墌 pg. 20)
Backlight Compensation Button [BACK
LIGHT] (墌 pg. 31)
B Play/Pause Button [4/9] (墌 pg. 20)
Manual Focus Button [FOCUS] (墌 pg. 29)
C Rewind Button [3] (墌 pg. 20)
Menu select Button [–] (墌 pg. 14)
Quick Review Button [ ] (墌 pg. 19)
D Fast-Forward Button [5] (墌 pg. 20)
Menu select Button [+] (墌 pg. 14)
Night Button [NIGHT] (墌 pg. 28)
E Menu Button [MENU] (墌 pg. 22)
Data Battery Button [DATA] (墌 pg. 12)
F Dioptre Adjustment Control (墌 pg. 15)
G Snapshot Button [SNAPSHOT] (墌 pg. 29)
H Power Zoom Lever [T/W] (墌 pg. 18)
Speaker Volume Control [VOL. +, –]
(墌 pg. 20)
I Battery Release Button [PUSH BATT.]
(墌 pg. 11)
J Recording Start/Stop Button (墌 pg. 17)
K Power Switch [A, M, PLAY, OFF] (墌 pg. 13)
L Lock Button (墌 pg. 13)
M Cassette Open/Eject Switch [OPEN/EJECT]
(墌 pg. 16)
Connectors
The connectors are located beneath the covers.
N S-Video/Audio/Video Output Connector [S/
AV] (墌 pg. 21, 35)
O DC Input Connector [DC] (墌 pg. 11)
P Digital Video Connector [DV IN/OUT] (i.Link*)
(墌 pg. 36, 37)
Q Microphone connector [MIC] (墌 pg. 26)
(An optional microphone can be used during
video recording and audio dubbing. To
stabilise the microphone, use of an optional
shoe adapter is recommended.)
* i.Link refers to the IEEE1394-1995 industry
specification and extensions thereof. The logo
is used for products compliant with the i.Link
standard.
Indicators
R POWER/CHARGE Lamp (墌 pg. 11, 17)
Other Parts
S Monitor Latch (墌 pg. 18)
T LCD Monitor (墌 pg. 18, 19)
U Viewfinder (墌 pg. 15)
V Battery Pack Mount (墌 pg. 12)
W Shoulder Strap Eyelet (墌 pg. 11)
X Speaker (墌 pg. 20)
Y Grip Strap (墌 pg. 14)
Z Lens
a Camera Sensor
(Be careful not to cover this area, a sensor
necessary for shooting is built-in here.)
b Stereo Microphone
c Stud Hole (墌 pg. 15)
d Tripod Mounting Socket (墌 pg. 15)
e Cassette Holder Cover (墌 pg. 16)
To Next Page
