(No.YF008)3-17
MONI-C BOARD ASSEMBLY <02> [S TYPE]
NOTE :
There are two types of VF(COLOR) ASSEMBLY used for this model:
S type and K type.
For methods to distinguish the two types, see Cover Page.
R8042 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J K,L,M,N
R8043 NRSA6AJ-220W MG RESISTOR 22 Ω 1/16W J F, G, H, J, K ,L ,M ,N
R8046 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J F, G, H, J, K ,L ,M ,N
R8051 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J F, G, H, J, K ,L ,M ,N
R8054 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J F, G, H, J, K ,L ,M ,N
R8056 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J F, G, H, J, K ,L ,M ,N
R8059 NRSA6AJ-473W MG RESISTOR 47k Ω 1/16W J F, G, H, J, K ,L ,M ,N
R8063 NRSA6AJ-220W MG RESISTOR 22 Ω 1/16W J F, G, H, J, K ,L ,M ,N
R8065 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J K,L,M,N
R8066 NRSA6AJ-103W MG RESISTOR 10k Ω 1/16W J F,G,H,J
R8066 NRSA6AJ-473W MG RESISTOR 47k Ω 1/16W J K,L,M,N
R8067 NRSA6AJ-103W MG RESISTOR 10k Ω 1/16W J F,G,H,J
R8068 NRSA6AJ-561W MG RESISTOR 560 Ω 1/16W J F, G, H, J, K ,L ,M ,N
R8069 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J F, G, H, J, K ,L ,M ,N
R8070 NRSA6AJ-220W MG RESISTOR 22 Ω 1/16W J F, G, H, J, K ,L ,M ,N
R8074 NRSA6AJ-473W MG RESISTOR 47k Ω 1/16W J F, G, H, J, K ,L ,M ,N
R8075 NRSA6AJ-102W MG RESISTOR 1k Ω 1/16W J F, G, H, J, K ,L ,M ,N
R8076 NRSA6AJ-220W MG RESISTOR 22 Ω 1/16W J F, G, H, J, K ,L ,M ,N
R8077 NRSA6AJ-220W MG RESISTOR 22 Ω 1/16W J F, G, H, J, K ,L ,M ,N
R8078 NRSA6AJ-220W MG RESISTOR 22 Ω 1/16W J F, G, H, J, K ,L ,M ,N
R8079 NRSA6AJ-221W MG RESISTOR 220 Ω 1/16W J F, G, H, J, K ,L ,M ,N
R8302 NRS181J-220X MG RESISTOR 22 Ω 1/8W J F, G, H, J, K ,L ,M ,N
R8303 NRS181J-220X MG RESISTOR 22 Ω 1/8W J F, G, H, J, K ,L ,M ,N
R8305 NRSA6AJ-105W MG RESISTOR 1M Ω 1/16W J F, G, H, J, K ,L ,M ,N
R8306 NRSA6AJ-103W MG RESISTOR 10k Ω 1/16W J F, G, H, J, K ,L ,M ,N
R8307 NRSA6AJ-103W MG RESISTOR 10k Ω 1/16W J F, G, H, J, K ,L ,M ,N
R8308 NRSA6AJ-103W MG RESISTOR 10k Ω 1/16W J F, G, H, J, K ,L ,M ,N
R8309 NRSA6AJ-103W MG RESISTOR 10k Ω 1/16W J F, G, H, J, K ,L ,M ,N
R8313 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J F, G, H, J, K ,L ,M ,N
R8314 NRSA6AJ-105W MG RESISTOR 1M Ω 1/16W J F, G, H, J, K ,L ,M ,N
R8315 NRSA6AJ-105W MG RESISTOR 1M Ω 1/16W J F, G, H, J, K ,L ,M ,N
R8716 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J F, G, H, J, K ,L ,M ,N
R8717 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J F, G, H, J, K ,L ,M ,N
RA1001 NRZ0034-473W NET RESISTOR 47k Ω 1/32W J
RA1002 NRZ0034-104W NET RESISTOR 100k Ω 1/32W J
RA1004 NRZ0034-104W NET RESISTOR 100k Ω 1/32W J
RA1005 NRZ0034-103W NET RESISTOR 10k Ω 1/32W J
RA1006 NRZ0034-102W NET RESISTOR 1k Ω 1/32W J
RA1007 NRZ0034-102W NET RESISTOR 1k Ω 1/32W J
RA1008 NRZ0034-104W NET RESISTOR 100k Ω 1/32W J
RA3001 NRZ0034-560W NET RESISTOR 56 Ω 1/32W J
RA3002 NRZ0034-560W NET RESISTOR 56 Ω 1/32W J
RA3003 NRZ0034-100W NET RESISTOR 10 Ω 1/32W J
RA3004 NRZ0034-103W NET RESISTOR 10k Ω 1/32W J
RA3005 NRZ0040-0R0X NET RESISTOR 0 Ω 1/16W J
RA8001 NRZ0034-101W NET RESISTOR 100 Ω 1/32W J F, G, H, J, K ,L ,M ,N
RA8002 NRZ0034-101W NET RESISTOR 100 Ω 1/32W J F, G, H, J, K ,L ,M ,N
RA8003 NRZ0034-101W NET RESISTOR 100 Ω 1/32W J F, G, H, J, K ,L ,M ,N
RA8004 NRZ0034-101W NET RESISTOR 100 Ω 1/32W J F, G, H, J, K ,L ,M ,N
L1001 NQL402M-100X COIL 10uH M
L1002 NQL402M-100X COIL 10uH M
L2101 NQL38DK-100X P COIL 10uH K F, G, H, J, K ,L ,M ,N
L2401 NQL402M-100X COIL 10uH M
L2402 NQL402M-100X COIL 10uH M
L3001 NQR0129-002X FERRITE BEADS
L3002 NQR0129-002X FERRITE BEADS
L3004 NQR0006-001X FERRITE BEADS
L3005 NQR0006-001X FERRITE BEADS
L3007 NQL085J-2R2X COIL 2.2uH J
L3008 NQL085J-120X COIL 12uH J
L3012 NQR0129-002X FERRITE BEADS
L3014 NQL38DK-100X P COIL 10uH K
L3015 NQR0006-001X FERRITE BEADS
L3201 NQR0129-002X FERRITE BEADS
L3202 NQR0129-002X FERRITE BEADS
L3203 NQR0006-001X FERRITE BEADS
L3204 NQL38DK-100X P COIL 10uH K
L3701 NQL38DK-100X P COIL 10uH K
L3731 NQL085J-6R8X COIL 6.8uH J
F, G, H, J, K ,L ,M ,N
L3732 NQL085J-2R2X COIL 2.2uH J F, G, H, J, K ,L ,M ,N
L4201 NQR0129-002X FERRITE BEADS
L4301 NQR0129-002X FERRITE BEADS
L4302 NQR0129-002X FERRITE BEADS
L4802 NQL302N-100X COIL 10uH N
L4851 NQR0129-002X FERRITE BEADS
L4852 NQL38DK-100X P COIL 10uH K
L4853 NQL38DK-100X P COIL 10uH K
 Symbol No. Part No. Part Name Description Local
L5501 NQL38DK-100X P COIL 10uH K
L5502 NQR0129-002X FERRITE BEADS
L5503 NQR0129-002X FERRITE BEADS
L5504 NQR0129-002X FERRITE BEADS
L5505 NQL38DK-100X P COIL 10uH K
L5506 NQL38DK-100X P COIL 10uH K
L6001 NQL52EN-4R7X COIL 4.7uH N F,G,H,J,K,L,M,N
L6101 NQL52EM-390X COIL 39uH M
L6201 NQL82EN-390X COIL 39uH N
L6301 NQL52EM-390X COIL 39uH M
L6302 NQL144K-220X P COIL 22uH K
L6401 NQL52EM-470X COIL 47uH M
L6501 NQL52EM-470X COIL 47uH M
L6601 NQLZ011-221X COIL 220uH M
L6701 NQL73EM-100X COIL 10uH M
L6801 NQL79GM-470X COIL 47uH M
L8001 NQR0129-002X FERRITE BEADS F,G,H,J,K,L,M,N
L8002 NQR0129-002X FERRITE BEADS F,G,H,J,K,L,M,N
L8003 NQR0129-002X FERRITE BEADS F,G,H,J,K,L,M,N
L8004 NQR0129-002X FERRITE BEADS F,G,H,J,K,L,M,N
L8005 NQR0129-002X FERRITE BEADS F,G,H,J,K,L,M,N
L8006 NQR0129-002X FERRITE BEADS F,G,H,J,K,L,M,N
L8301 NQR0129-002X FERRITE BEADS F,G,H,J,K,L,M,N
CN101 QGF0528F1-40X CONNECTOR MONITOR L FFC/FPC (1-40)
CN102 QGF0508F1-06X CONNECTOR FRONT FFC/FPC (1-6)
CN103 QGF0534F1-10X CONNECTOR SD CARD L FFC/FPC (1-10) K,L,M,N
CN104 QGA1002C1-08X CONNECTOR REAR W W-B (1-8)
CN105 QGB0801M1-30X CONNECTOR JIG CN B B-B (1-30)
CN106 QGA1001F1-04X CONNECTOR MIC W W-B (1-4)
CN107 QGF0512C1-20X CONNECTOR CCD S FFC/FPC (1-20)
CN108 QGF0512C1-24X CONNECTOR OP S FFC/FPC (1-24)
CN109 QGF0534F1-16X CONNECTOR OPE UNITL FFC/FPC (1-16)
CN110 QGF0508F1-40X CONNECTOR PRE/MDA L FFC/FPC (1-40)
CN111 QGF0508F1-40X CONNECTOR PRE/MDA L FFC/FPC (1-40)
CN112 QGF0512C1-12X CONNECTOR REAR FFC/FPC (1-12)
 F6001 NMFZ007-2R5X-K FUSE 2.5A 24V
 F6301 NMFZ007-1R25X-K FUSE 1.25A 32V
 F6801 NMFZ007-R50X-K FUSE 0.5A 50V
J501 NNZ0041-001X D CONNECTOR DV IEEE1394(4pin)
J502 QNZ0616-001 USB CONNECTOR USB F,G,H,J,K,L,M,N
X1001 NAX0630-001 CRYSTAL
X1002 NAX0564-001X CRYSTAL
X3002 NAX0480-001X CRYSTAL 24.576MHz
X5501 NAX0587-001X CXO
X8301 NAX0612-001X C RESONATOR F,G,H,J,K,L,M,N
OT1 LY30030-0Y7A SPACER(A) SPACER
OT2 LY30030-0Y3A SPACER(A)
OT3 LY44551-001A SHEET(MA2) MAIN A,B,C,D,E
OT3 LY44549-001A SHIELD SHEET F,G,H,J,K,L,M,N
OT4 LY44552-001A BUSTERAID MAIN A,B,C,D,E
WR1 WJT0122-001A E-CARD WIRE MAN-PRE/MD(x2)
 Symbol No. Part No. Part Name Description Local
PW1 YB10447A-02 MONI-C BOARD ASSY K,L,M,N
PW1 YB10447B-02 MONI-C BOARD ASSY
A,B,C,D,E,F,G,H,J
IC7601 AN2540FHQ IC
IC7602 RC4558D-X IC
IC7604 SN74LV08APW-X IC
IC7606 MM1613AN-X IC
Q7601 2SC4617/QR/-X TRANSISTOR
Q7601 or 2SC4738/YG/-X TRANSISTOR
Q7601 or 2SD2216J/QR/-X TRANSISTOR
Q7601 or BC847BT-X TRANSISTOR
Q7602 2SA1774/QR/-X TRANSISTOR
Q7602 or 2SA1832/YG/-X TRANSISTOR
 Symbol No. Part No. Part Name Description Local
MODEL MARK
GR-D23EK
GR-D23EX
GR-D23EY
GR-D23EZ
A
B
C
D
MODEL MARK
GR-D33EK
GR-D53EK
GR-D53EX
GR-D53EY
E
F
G
H
MODEL MARK
GR-D53EZ
GR-D73EK
GR-D73EX
GR-D73EY
J
K
L
M
MODEL MARK
GR-D73EZ N
