SCHEMATIC DIAGRAMS
COPYRIGHT © 2004 VICTOR COMPANY OF JAPAN, LIMITED
No.YF008SCH
2004/1
DIGITAL VIDEO CAMERA
YF00820041
GR-D23EK, GR-D23EX, GR-D23EY, GR-D23EZ,
GR-D33EK, GR-D53EK, GR-D53EX,
GR-D53EY, GR-D53EZ, GR-D73EK,
GR-D73EX, GR-D73EY, GR-D73EZ
For disassembling and assembling of MECHANISM ASSEMBLY, refer to the SERVICE MANUAL No.86700 (MECHANISM ASSEMBLY).
GR-D23EK,GR-D23EX,GR-D23EY,GR-D23EZ[M4D1S2],GR-D33EK[M4D1S3]
GR-D53EK,GR-D53EX,GR-D53EY,GR-D53EZ[M4D1S5]
GR-D73EK,GR-D73EX,GR-D73EY,GR-D73EZ[M4D1S7]
NOTE :
There are two types of VF(COLOR) ASSEMBLY used for this model: S type and K type.
Prior to repair operation related to VIEW FINDER, be sure to see the VF(COLOR)
ASSEMBLY and Parts List.
Methods to distinguish the two types are as follows:
1. Distinction based on EEPROM DATA (EEPROM utility)
2. Distinction based on a part number of the MONI-C BOARD ASSEMBLY.
3. Distinction based on a sticker attached to the VF(COLOR) ASSEMBLY.
S TYPE K TYPE
EEPROM DATA ADRS 3CCH:01H ADRS 3CCH:05H
MONI-C PWB YB10447 SERIES YB10453 SERIES
VF(COLOR) ASSY NO STICKER STICKER ON TOP FACE
STICKER
VF(COLOR) ASSEMBLY
