JVC GR-D33EK - Page 54

2-59 2-60
REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION
COMPONENT PARTS LOCATION GUIDE <MAIN> YB10449-01-01
CAPACITOR
C1001 B C 4B
C1002 B C 4B
C1003 B C 4B
C1004 B C 4B
C1005 B C 4B
C1006 B C 4B
C1007 B C 3A
C1008 B C 4B
C1009 B C 4B
C1010 A C 5B
C1011 B C 4B
C1012 B C 4B
C1013 B C 4B
C1014 B C 4B
C1015 B C 4B
C1016 B C 4A
C1017 B C 4B
C1018 B C 4B
C1019 B C 4B
C1020 B C 4A
C1021 B C 4A
C1022 B C 4B
C1024 B C 5B
C1025 B C 4A
C1029 B C 4B
C1030 B C 4A
C1032 B C 4B
C1035 B C 4A
C1036 A C 3A
C1037 B C 4C
C1038 B C 4C
C1039 B C 5A
C1040 B C 4C
C1041 B C 4A
C1042 B C 3C
C1043 B C 4B
C1044 B C 3B
C1045 B C 4B
C1046 A C 4A
C1047 B C 4B
C1048 B C 4B
C1049 B C 4B
C1050 B C 4B
C1051 B C 4A
C1052 B C 4A
C1053 B C 4A
C1054 B C 4A
C1055 B C 4B
C1057 B C 4B
C1058 B C 4B
C1059 B C 4B
C1060 B C 5A
C1061 B C 4A
C1062 B C 4A
C1064 B C 2C
C1065 B C 4B
C1102 A C 5B
C1103 A C 5B
C1104 A C 5B
C1105 A C 5B
C1106 A C 5B
C1107 A C 5B
C1151 B C 5B
C1152 B C 5B
C2201 A C 4A
C2202 A C 4A
C2203 A C 4A
C2204 A C 4A
C2205 A C 4A
C2209 A C 4A
C2210 A C 4A
C2213 A C 4A
C2214 A C 4A
C2215 A C 4A
C2216 A C 4A
C2217 A C 4A
C2218 A C 4A
C2219 A C 4A
C2220 A C 4A
C2221 A C 4A
C2222 A C 4A
C2223 A C 4A
C2224 A C 4A
C2401 A C 4A
C2402 A C 4A
C2403 A C 4A
C2404 A C 4A
C2405 A C 4A
C2406 A C 4A
C2603 A C 4A
C2604 A C 4A
C2605 A C 4A
C2606 A C 4A
C2607 A C 4A
C2608 A C 4A
C2611 A C 4A
C2612 A C 5A
C2613 A C 4A
C2614 A C 4A
C2615 A C 4A
C2616 A C 4A
C2617 A C 5A
C2618 A C 5A
C2619 A C 5A
C3001 B C 2B
C3003 B C 2A
C3005 B C 2A
C3006 B C 1A
C3007 B C 2B
C3008 B C 2A
C3009 B C 2A
C3011 B C 2A
C3012 B C 2A
C3013 B C 3B
C3015 B C 2A
C3016 B C 2A
C3017 B C 3B
C3020 B C 2A
C3021 B C 2A
C3022 B C 3A
C3023 B C 3A
C3024 B C 3A
C3025 B C 2B
C3026 A C 1A
C3027 B C 2B
C3028 A C 1A
C3029 B C 2B
C3030 B C 3B
C3031 B C 2A
C3032 B C 3B
C3033 B C 3B
C3036 B C 3B
C3037 B C 3B
C3038 B C 2B
C3039 B C 2B
C3040 B C 3B
C3042 B C 2B
C3043 B C 3B
C3044 B C 2A
C3045 B C 2B
C3046 B C 2B
C3047 B C 3B
C3048 B C 2A
C3049 B C 2A
C3050 B C 2B
C3055 B C 2B
C3056 B C 2A
C3059 B C 3A
C3060 B C 3A
C3064 B C 3B
C3066 B C 2A
C3067 B C 2A
C3068 B C 2A
C3069 B C 2A
C3070 B C 2A
C3071 A C 3B
C3075 B C 2B
C3201 A C 3B
C3202 A C 3B
C3203 A C 3B
C3204 A C 2A
C3205 A C 2A
C3206 A C 3B
C3207 A C 3A
C3208 A C 3A
C3209 A C 3A
C3210 A C 3A
C3211 A C 3A
C3212 A C 3A
C3213 A C 3A
C3214 A C 3A
C3215 A C 2A
C3216 A C 2A
C3217 A C 2A
C3218 A C 2A
C3219 A C 2A
C3220 A C 2B
C3221 A C 2B
C3222 A C 3B
C3223 A C 2B
C3224 A C 2B
C3225 A C 2B
C3226 A C 3B
C3227 A C 3B
C3228 A C 3B
C3229 A C 3B
C3230 A C 3B
C3231 A C 3B
C3232 A C 3B
C3233 A C 3B
C3234 A C 3B
C3235 A C 3B
C3236 A C 3B
C3237 A C 3B
C3238 A C 3B
C3701 A C 2A
C3702 A C 3A
C3703 A C 3A
C3704 A C 3A
C3705 A C 3A
C3706 A C 3A
C3707 A C 3A
C3708 A C 2A
C3709 A C 2A
C3712 B C 1A
C3713 B C 1A
C3714 A C 2A
C3715 A C 3A
C4201 A C 3C
C4202 A C 2C
C4203 A C 2B
C4204 A C 3C
C4205 A C 3B
C4206 A C 3C
C4207 A C 3C
C4208 A C 3C
C4209 A C 3C
C4210 A C 3C
C4211 A C 3C
C4212 A C 3C
C4213 A C 3C
C4214 A C 3C
C4216 A C 3C
C4301 A C 4B
C4302 A C 3B
C4303 A C 3B
C4304 A C 4B
C4305 A C 4B
C4306 A C 4C
C4307 A C 3C
C4308 A C 3B
C4309 A C 3B
C4310 A C 4B
C4311 A C 4B
C4312 A C 4C
C4313 A C 3B
C4314 A C 3B
C4315 A C 3B
C4316 A C 3B
C4318 A C 3C
C4803 A C 4B
C4804 A C 4B
C4806 A C 4C
C4807 A C 4C
C4808 A C 4B
C4809 A C 4C
C4810 A C 4B
C4811 A C 4B
C4813 A C 4B
C4814 A C 4C
C4815 A C 4C
C4819 A C 4C
C4820 A C 4C
C4822 A C 4C
C4823 A C 4C
C4851 B C 3C
C4852 B C 3C
C4853 B C 3C
C4854 B C 3C
C4855 B C 3C
C4858 B C 4C
C4859 B C 4C
C4860 B C 4C
C4861 B C 4C
C4862 B C 4C
C4863 B C 4C
C4864 A C 3C
C4865 A C 3C
C4866 B C 3C
C5501 A C 2C
C5503 A C 2C
C5504 A C 2C
C5506 A C 2C
C5507 A C 2C
C5508 A C 2B
C5509 A C 2B
C5510 A C 2C
C5511 A C 2C
C5512 A C 2C
C5513 A C 2C
C5514 A C 2C
C5515 A C 2B
C5516 A C 2C
C5517 A C 2B
C5518 A C 2B
C5519 A C 2C
C6001 B C 1C
C6002 A C 1B
C6003 A C 1B
C6004 A C 1A
C6021 B C 1C
C6022 B C 1C
C6023 B C 1B
C6024 B C 1B
C6025 B C 1B
C6026 B C 1B
C6027 B C 1B
C6028 B C 1B
C6029 B C 1B
C6030 B C 1B
C6031 B C 1B
C6032 B C 1B
C6033 B C 1B
C6034 B C 1B
C6035 B C 1B
C6036 B C 1B
C6037 B C 2B
C6038 B C 1B
C6039 B C 2C
C6040 B C 1B
C6041 B C 1B
C6042 B C 1C
C6043 B C 1C
C6044 B C 1C
C6045 B C 1C
C6046 B C 1B
C6101 A C 1B
C6103 A C 1C
C6104 B C 1B
C6105 B C 1C
C6106 B C 1A
C6201 A C 1B
C6203 A C 1B
C6204 B C 1B
C6301 A C 1B
C6303 A C 1B
C6304 B C 1B
C6305 A C 2B
C6401 A C 2A
C6403 A C 2A
C6404 B C 1B
C6405 B C 1B
C6501 A C 2A
C6503 A C 2A
C6504 B C 1B
C6505 B C 2B
C6601 A C 2B
C6602 A C 2B
C6603 A C 2B
C6604 B C 1B
C6605 A C 3B
C6606 A C 2B
C6607 A C 2B
C6608 A C 2B
C6609 A C 2B
C6610 A C 2B
C6701 A C 1B
C6703 A C 1B
C6704 B C 1B
C6801 B C 1C
C6802 B C 2C
C6804 B C 1C
C6805 B C 1C
C6807 B C 1C
C6809 B C 1C
CONNECTOR
CN101 A C 3A
CN102 A C 5A
CN104 A C 1B
CN105 A C 1A
CN106 A C 5A
CN107 A C 3C
CN108 A C 3C
CN109 A C 2C
CN110 B C 2A
CN111 B C 4A
CN112 A C 1C
CN113 A C 3B
DIODE
D1001 A C 4A
D2202 A C 4A
D3001 B C 3A
D3002 B C 3B
D3003 B C 3B
D3004 B C 2B
D3701 A C 2A
D4301 A C 3B
D5501 A C 2C
D6601 A C 2B
D6602 A C 2B
D6603 A C 3B
D6701 A C 1B
D6702 A C 1B
D6801 B C 1C
FUSE
F6001 A C 1B
F6301 A C 1C
F6801 A C 1B
IC
IC1001 B C 4B
IC1002 A C 3A
IC1003 B C 4C
IC1004 B C 4C
IC1005 B C 5A
IC1006 B C 4C
IC1007 B C 4B
IC1101 A C 5B
IC1151 A D 5B
IC2201 A C 4A
IC3001 B C 2B
IC3002 B C 3A
IC3004 A C 3B
IC3005 B C 2A
IC3201 A C 3A
IC3202 A C 3B
IC3701 A C 2A
IC4201 A C 3C
IC4202 A C 2C
IC4301 A C 3B
IC4302 A C 3B
IC4802 A C 4C
IC4804 A C 4C
IC4807 A C 4C
IC4851 B C 3C
IC5501 A C 2C
IC6001 B C 1B
IC6801 B C 1C
COIL
L1001 B C 2C
L1002 B C 3C
L2401 A C 4A
L2402 A C 4A
L3001 B C 2A
L3002 B C 1A
L3004 B C 2A
L3005 B C 2B
L3007 B C 3A
L3008 B C 3B
L3012 B C 2A
L3014 B C 3A
L3015 B C 2A
L3201 A C 3B
L3202 A C 3B
L3203 A C 2A
L3204 A C 2A
L3701 A C 2A
L4201 A C 2B
L4301 A C 3B
L4302 A C 3C
L4802 A C 4B
L4851 B C 3C
L4852 B C 3C
L4853 A C 3C
L5501 A C 2C
L5502 A C 2C
L5503 A C 2C
L5504 A C 2B
L5505 A C 2C
L5506 A C 2B
L6001 A C 1B
L6002 A C 1A
L6101 A C 1C
L6201 A C 2B
L6301 A C 1C
L6302 B C 1B
L6401 A C 2A
L6501 A C 2A
L6601 A C 2B
L6701 A C 1B
L6801 B C 1C
TRANSISTER
Q1001 B C 4A
Q1002 B C 4A
Q1003 B C 4A
Q1004 B C 2C
Q1005 B C 3A
Q1006 A C 4B
Q1007 A C 4A
Q1008 A C 4A
Q1009 B C 5B
Q1010 B C 4C
Q1101 A D 5B
Q2001 B C 2C
Q2002 B C 2C
Q2003 B C 2C
Q2004 B C 2C
Q2005 B C 2C
Q2006 B C 3C
Q2202 A C 4A
Q2401 A C 4A
Q2403 A C 4A
Q3001 B C 1A
Q3002 B C 2A
Q3701 A C 3A
Q3702 A C 2A
Q3704 A C 3A
Q3705 A C 3A
Q4801 A C 4C
Q4802 A C 4C
Q4803 A C 4B
Q4804 A C 4B
Q4805 A C 4B
Q4806 A C 4B
Q4851 A C 4C
Q6101 A C 1C
Q6102 B C 1B
Q6201 A C 1B
Q6301 A C 1B
Q6302 A C 2B
Q6303 A C 2B
Q6401 A C 2B
Q6501 A C 2A
Q6601 A C 2B
Q6602 A C 2B
Q6603 A C 2B
Q6604 A C 2B
Q6605 A C 2B
Q6606 A C 2B
Q6701 A C 1B
Q6801 B C 1C
RESISTOR
R1001 B C 4B
R1002 B C 4A
R1003 B C 4A
R1006 B C 4B
R1007 B C 3B
R1008 B C 3B
R1009 A C 4B
R1011 A C 5B
R1012 B C 3B
R1013 B C 4B
R1014 B C 4B
R1015 B C 5B
R1016 B C 4B
R1017 B C 4A
R1018 B C 4B
R1019 B C 2C
R1020 B C 5B
R1021 B C 4B
R1022 B C 2C
R1023 B C 2C
R1024 B C 4B
R1025 B C 4A
R1026 A C 4A
R1028 B C 4A
R1029 B C 5B
R1030 B C 4B
R1031 B C 4B
R1032 B C 4A
R1033 B C 4A
R1034 B C 4A
R1035 B C 4B
R1036 B C 4B
R1037 B C 2C
R1038 B C 4A
R1039 B C 4B
R1040 B C 4B
R1043 B C 4C
R1044 B C 4C
R1045 B C 4C
R1046 B C 4C
R1047 B C 4C
R1048 B C 4C
R1049 B C 4C
R1050 B C 4C
R1051 B C 5A
R1052 B C 5A
R1053 B C 4B
R1054 B C 4B
R1055 B C 3B
R1056 B C 4B
R1057 B C 4B
R1058 B C 3B
R1059 B C 3B
R1060 B C 4A
R1062 B C 5B
R1063 A C 5B
R1064 A C 5B
R1065 A C 5B
R1066 A C 5B
R1067 B C 5B
R1068 B C 4B
R1069 B C 5B
R1070 A C 4A
R1071 A C 4A
R1072 A C 4A
R1073 A C 4A
R1074 A C 4A
R1075 A C 4A
R1076 B C 4B
R1077 B C 4B
R1078 B C 4B
R1079 B C 4B
R1080 B C 4B
R1081 B C 4B
R1082 B C 4B
R1083 B C 3B
R1084 B C 4A
R1085 B C 4A
R1086 B C 4A
R1087 B C 4A
R1088 B C 4A
R1089 B C 4A
R1091 B C 4B
R1092 B C 4B
R1093 B C 4A
R1094 B C 4A
R1095 B C 4B
R1096 B C 5B
R1097 B C 4B
R1099 B C 4B
R1101 A C 4B
R1102 A C 4B
R1103 A C 4B
R1104 A C 5B
R1105 A C 5B
R1106 A C 4B
R1107 A C 4B
R1108 A C 5B
R1151 B C 5B
R2001 B C 2C
R2002 B C 2C
R2003 B C 2C
R2004 B C 2C
R2005 B C 2C
R2006 B C 2C
R2007 B C 2C
R2008 B C 2C
R2009 B C 2C
R2010 B C 2C
R2011 B C 3C
R2012 B C 3C
R2013 B C 2C
R2014 B C 2C
R2015 B C 2C
R2016 B C 2C
R2017 B C 2C
R2018 B C 3C
R2201 A C 4A
R2202 A C 4A
R2203 A C 4A
R2204 A C 4A
R2206 A C 4A
R2207 A C 4A
R2208 A C 4A
R2209 A C 4A
R2210 A C 4A
R2211 A C 4A
R2212 A C 4A
R2213 A C 4A
R2217 A C 4A
R2218 A C 4A
R2219 A C 4A
R2220 A C 4A
R2221 A C 4A
R2222 A C 4A
R2223 A C 4A
R2224 A C 4A
R2225 A C 4A
R2226 A C 4A
R2229 A C 4A
R2230 A C 4A
R2231 A C 4A
R2401 A C 4A
R2402 A C 4A
R2403 A C 4A
R2407 A C 4A
R2601 A C 4A
R2602 A C 4A
R2607 A C 4A
R2608 A C 4A
R2609 A C 4A
R2610 A C 4A
R2611 A C 4A
R2612 A C 5A
R2613 A C 4A
R2614 A C 4A
R3002 B C 2A
R3004 B C 2A
R3005 B C 3B
R3006 B C 3B
R3007 B C 2A
R3008 B C 2A
R3009 B C 3A
R3010 B C 3A
R3011 B C 3A
R3013 B C 2B
R3014 B C 2B
R3015 B C 2B
R3016 A C 1A
R3017 A C 1A
R3018 A C 1A
R3019 A C 1A
R3020 A C 1A
R3021 B C 2B
R3022 B C 2B
R3025 B C 1A
R3026 B C 1A
R3027 B C 3B
R3029 B C 3B
R3030 B C 3B
R3031 B C 3B
R3032 B C 3B
R3034 B C 3B
R3036 B C 2A
R3037 B C 2A
R3057 B C 2A
R3066 B C 2A
R3067 B C 2A
R3068 B C 2A
R3069 B C 2A
R3071 B C 2A
R3072 B C 2A
R3073 B C 2A
R3074 B C 2A
R3075 B C 3A
R3077 A C 3B
R3078 A C 3B
R3201 A C 3A
R3202 A C 2A
R3203 A C 2A
R3204 A C 2A
R3205 A C 2B
R3206 A C 3B
R3207 A C 3B
R3208 A C 3B
R3209 A C 3B
R3210 A C 3A
R3211 A C 3A
R3212 A C 2B
R3213 A C 2B
R3214 A C 2B
R3338 A C 2A
R3339 A C 2A
R3701 A C 3A
R3702 A C 3A
R3703 A C 3A
R3704 A C 3A
R3705 A C 3A
R3706 A C 3A
R3707 A C 2A
R3708 B C 1A
R3709 B C 1A
R3710 A C 2A
R3711 A C 2A
R3712 A C 2A
R3713 A C 2A
R3714 A C 2A
R3715 A C 2A
R3722 A C 3A
R3724 A C 3A
R3725 A C 3A
R3726 A C 3A
R3727 A C 3A
R3728 A C 3A
R3730 A C 3A
R4201 A C 3C
R4202 A C 3C
R4203 A C 3C
R4204 A C 3B
R4301 A C 3B
R4302 A C 3B
R4303 A C 3B
R4304 A C 3B
R4306 A C 3B
R4307 A C 4B
R4308 A C 3B
R4309 A C 3C
R4310 A C 3C
R4311 A C 3C
R4312 A C 3C
R4314 A C 3B
R4315 A C 3B
R4316 A C 3B
R4317 A C 3B
R4318 A C 3B
R4319 A C 3B
R4320 A C 3B
R4321 A C 3B
R4326 A C 3B
R4327 A C 3B
R4328 A C 4B
R4329 A C 4B
R4330 A C 4B
R4331 A C 4B
R4332 A C 4B
R4333 A C 3B
R4334 A C 3B
R4339 A C 3B
R4341 A C 4B
R4342 A C 3C
R4343 A C 3C
R4344 A C 3C
R4345 A C 3C
R4346 A C 3C
R4354 A C 3B
R4804 A C 4C
R4805 A C 4C
R4806 A C 4B
R4807 A C 4B
R4808 A C 4C
R4809 A C 4C
R4810 A C 4C
R4811 A C 4B
R4812 A C 4B
R4813 A C 4B
R4814 A C 4B
R4815 A C 4B
R4816 A C 4B
R4817 A C 4C
R4818 A C 4C
R4819 A C 4B
R4820 A C 4B
R4821 A C 4B
R4822 A C 4B
R4823 A C 4C
R4824 A C 4B
R4825 A C 4C
R4826 A C 4C
R4827 A C 4C
R4828 A C 4C
R4829 A C 4C
R4830 A C 4B
R4831 A C 4C
R4833 A C 4C
R4836 A C 4C
R4837 A C 4B
R4839 A C 4C
R4840 A C 4C
R4841 A C 4C
R4842 A C 4C
R4843 A C 4B
R4844 A C 4B
R4845 A C 4C
R4846 A C 4B
R4847 A C 4B
R4849 A C 4C
R4850 A C 4C
R4852 B C 3C
R4854 B C 4C
R4855 B C 4C
R4856 B C 4C
R4857 B C 4C
R4858 B C 4C
R4859 B C 4C
R4860 B C 4C
R4862 B C 3C
R4863 B C 3C
R4864 B C 3C
R4865 B C 3C
R4866 B C 3C
R4867 B C 3C
R4868 B C 3C
R4870 A C 4C
R4871 B C 3C
R4872 B C 4C
R4873 B C 3C
R4874 A C 4C
R5501 A C 2B
R5502 A C 2B
R5503 A C 2C
R5504 A C 2C
R5505 A C 2C
R5506 A C 2C
R5507 A C 2C
R5509 A C 2B
R5511 A C 2C
R5512 A C 2C
R5513 A C 2C
R5514 A C 2C
R6021 B C 1C
R6022 B C 1C
R6023 B C 1C
R6024 B C 1C
R6025 B C 1C
R6026 B C 1C
R6027 B C 1B
R6028 B C 1B
R6029 B C 1B
R6030 B C 1B
R6031 B C 1B
R6032 B C 1B
R6033 B C 1B
R6034 B C 1B
R6035 B C 2B
R6036 B C 2B
R6037 B C 1B
R6038 B C 1C
R6040 B C 1C
R6041 B C 1C
R6042 B C 1B
R6043 B C 1C
R6044 B C 1C
R6045 B C 1B
R6046 B C 1B
R6047 B C 1B
R6048 A C 1B
R6049 A C 1A
R6102 B C 1B
R6103 B C 1B
R6104 B C 1B
R6105 B C 1B
R6106 B C 1B
R6107 B C 1C
R6108 B C 1C
R6109 B C 1B
R6110 B C 1B
R6202 B C 1B
R6203 B C 1B
R6204 B C 1B
R6302 B C 1B
R6303 B C 1B
R6305 A C 2B
R6306 A C 2B
R6307 A C 2B
R6308 A C 2B
R6309 A C 2A
R6310 B C 1B
R6402 B C 1B
R6403 B C 1B
R6405 B C 1B
R6406 B C 1B
R6407 B C 1B
R6502 B C 2B
R6503 B C 2B
R6505 B C 1B
R6506 B C 1B
R6602 B C 1B
R6603 B C 1B
R6604 B C 1B
R6605 B C 1B
R6606 A C 2B
R6607 A C 2B
R6608 A C 2B
R6609 A C 2B
R6610 A C 2B
R6611 A C 2B
R6612 A C 2B
R6613 A C 2B
R6614 A C 2B
R6615 A C 2B
R6616 A C 2B
R6617 A C 2B
R6618 A C 2B
R6619 A C 2B
R6701 A C 1B
R6702 B C 1B
R6703 B C 1B
R6704 B C 1B
R6705 B C 1B
R6706 A C 1C
R6707 A C 1C
R6708 A C 1B
R6709 A C 1B
R6803 B C 1C
R6804 B C 1C
R6805 B C 1C
R6813 B C 1C
R6815 B C 1C
RA1001 B C 4B
RA1002 B C 2C
RA1004 B C 2C
RA1005 B C 2C
RA1006 B C 2C
RA1007 B C 2C
RA1008 B C 5B
RA3001 B C 3B
RA3002 B C 3B
RA3003 B C 3B
RA3004 B C 2A
RA3005 A C 1A
TEST POINT
TL1001 B C 4B
TL1003 B C 4B
TL1021 B C 3A
TL1022 B C 3A
TL1023 B C 3A
TL1024 B C 3A
TL1025 B C 3A
TL1026 B C 3B
TL3001 B C 3A
TL3006 B C 3A
TL3007 B C 2B
TL3008 B C 2B
TL3009 B C 2B
TL3011 B C 2B
TL3211 A C 3A
TL4301 A C 3C
TL4302 A C 3C
TL4303 A C 4C
TL4312 A C 4C
TL4313 A C 4C
TL4314 A C 4C
TL4315 A C 4C
OTHER
J501 A C 1A
TM4 A C 5C
TM8 A C 5C
TP110 B C 1B
X1001 B C 3B
X1002 B C 4C
X3002 B C 3B
X5501 A C 2B
