JVC GR-D33EK - VOLTAGE CHARTS

2-77 2-78
<CPU>
MODE
REC PLAY
PIN NO.
MODE
REC PLAY
PIN NO.
IC1001 - -
IC1002
1 2.7 2.7
2 2.4 2.4
3 0 2.7
4 0 3.0
5 3.0 3.1
6 0 0
7 0 0
8 1.4 1.5
9 0 0
10 0 0
11 0 0
12 0 0
13 0 0
14 0 0
15 0 0
16 0 0
17 0 0
18 0 0
19 2.9 3.0
20 2.8 2.8
IC1003
1 0 0
2 2.9 2.9
3 0 0
4 3.0 3.0
5 3.0 3.0
IC1004
1 0 1.5
2 0 0
3 1.2 1.3
4 0 0
5 3.0 3.0
IC1005
1 3.0 3.0
2 0 0
3 3.0 3.0
4 0 0
5 3.0 3.0
6 3.0 3.0
7 3.0 3.0
8 3.0 3.0
IC1006
1 0 0
2 3.0 3.0
3 3.0 3.0
4 0 0
5 0 0.4
6 0.4 0
7 0 0
8 3.0 3.1
IC1007
1 3.1 3.1
2 3.0 3.0
3 0 0
4 0 0
IC1101
1 2.4 2.4
2 2.4 2.4
3 0 2.4
4 0 0
5 2.4 2.4
6 2.4 2.4
7 1.7 1.8
8 4.8 4.8
IC1151
1 4.6 3.3
2 0 0
3 4.8 4.8
Q1001
E 3.0 3.1
C 0 3.1
B 3.0 3.1
Q1002
1 0 0
2 3.0 3.0
3 3.0 0
4 0 0
5 0 0
Q1003
1 0 0
2 0 0
3 3.1 0
4 -0.3 -0.9
5 3.1 3.0
Q1004
1 0 0
2 3.0 3.0
3 3.0 3.0
4 0 0
5 0 0
Q1005
E 0 0
C 0.7 1.1
B 0 0
Q1006
E 0 0
C 1.1 1.1
B 0 0
Q1007
E 0 0
C 3.1 3.1
B 0.5 0.6
Q1008
E 0 0
C 0 0
B 0 3.0
Q1009
D 3.0 3.0
S 0 0
G 3.0 3.0
Q1010
E 0 0
C 0 3.0
B 0 0
Q1101
E 0 0
C 4.3 4.3
B - -
<DV MAIN>
MODE
REC PLAY
PIN NO.
IC3001 - -
IC3002
1 0 0
2 0.5 0.5
3 0.4 0
4 2.6 2.6
5 1.6 1.6
6 2.4 2.4
7 1.2 1.2
8 3.1 3.1
9 3.1 3.1
10 0 3.1
11 3.1 3.1
12 2.0 2.0
13 1.6 1.6
14 0 0
15 0 0
16 3.0 3.0
17 3.0 3.0
18 1.5 1.5
19 0 0
20 0 0
IC3005
1 0 0.5
2 0 0
3 0 0
4 1.5 1.7
5 0 0
6 0 0
7 0 0
8 3.1 3.1
Q3001
E 1.8 1.8
C 2.8 2.8
B 2.4 2.8
Q3002
E 0.9 1.2
C 3.1 3.1
B 1.4 1.7
<REG>
MODE
REC PLAY
PIN NO.
MODE
REC PLAY
PIN NO.
IC6001
1 3.1 3.1
2 3.0 3.0
3 3.0 3.0
4 0 3.0
5 0 3.1
6 0 0
7 0 1.3
8 11.0 0
9 0 1.0
10 1.3 0
11 2.1 2.2
12 0 0
13 0 0
14 0 0
15 0 0
16 0 0
17 0 0.2
18 0 0
19 2.2 2.2
20 1.0 1.0
21 0 0
22 2.2 2.2
23 1.0 1.0
24 0.7 0.7
25 0 1.0
26 0 0.6
27 0 1.0
28 0.8 0.8
29 1.0 1.0
30 0.6 0.6
31 0.3 0
32 0.3 0.3
33 0.6 0.6
34 0.1 0.1
35 0.1 0.1
36 0.5 0.5
37 0.8 0.8
38 0 0
39 1.0 1.0
40 0 0
41 2.4 2.4
42 0 0
43 0 0
44 2.2 2.2
45 0 2.2
46 2.2 0
47 6.0 0
48 1.1 1.1
49 0 0
50 3.1 3.1
51 0 11.0
52 0 0
53 9.8 9.8
54 0 8.6
55 0 0
56 0 0
57 0 0
58 0 7.8
59 0 0
60 0 0
61 0 0
62 0 11.2
63 0 1.3
64 0 1.0
IC6801
1 11.0 11.0
2 0 0
3 1.0 1.0
4 10.1 10.1
5 11.0 11.0
Q6101
1 0 0
2 11.0 11.0
3 7.8 7.8
4 3.1 3.1
5 0 0
6 3.1 3.1
Q6102
E 3.1 3.1
C 2.8 2.5
B 3.0 3.1
Q6201
1 0 0
2 11.0 11.0
3 9.1 9.1
4 1.8 1.8
5 0 0
6 1.8 1.8
Q6301
1 0 0
2 11.0 11.0
3 5.9 6.0
4 4.9 4.9
5 0 0
6 4.9 4.9
Q6302
E 4.8 4.8
C -0.5 -0.2
B 4.8 4.8
Q6303
E 0 0
C 4.8 4.8
B 0 0
Q6401
1 0 0
2 11.0 11.0
3 8.5 8.6
4 0 2.7
5 0 0
6 2.7 2.7
Q6501
1 0 0
2 11.0 11.0
3 9.7 9.7
4 1.1 1.1
5 0 0
6 1.2 1.1
Q6601
D 11.0 11.0
S 8.3 8.3
G 0 0
Q6603
E 14.9 14.9
C 12.2 12.2
B 14.3 14.3
Q6604
E 0 0
C 14.9 14.9
B -1.0 -1.0
Q6605
1 -6.9 -7.0
2 -7.5 -7.5
3 -12.9 -14.5
4 -6.9 -7.0
5 -7.4 -7.4
6 -14.9 -14.9
Q6606
E -13.5 -14.9
C -7.4 -7.6
B -12.9 -14.5
Q6701
D 11.0 11.0
S 11.0 11.0
G 0 0
Q6801
1 0 0
2 0 10.8
3 11.0 11.0
4 3.2 3.2
5 3.2 3.2
<DSC>
MODE
REC PLAY
PIN NO.
MODE
REC PLAY
PIN NO.
IC8001 - -
IC8002
1 0 0
2 0 0
3 3.1 3.1
4 0 0
5 0 0
6 0 0
7 0 0
8 0 0
9 3.1 3.1
10 0 0
11 0 0
12 0 0
13 0 0
14 0 0
15 3.1 3.1
16 0 0
17 2.6 2.7
18 2.6 2.7
19 2.6 2.7
20 2.6 2.7
21 0 0
22 0 0
23 0 0
24 0 0
25 0 0
26 0 0
27 0 0
28 0 0
29 3.1 3.1
30 0 0
31 0 0
32 0 0
33 0 0
34 0 0
35 3.1 3.1
36 0 0
37 0 0
38 0 0
39 0 0
40 0 0
41 0 3.1
42 0 0
43 3.1 3.1
44 0 0
45 0 0
46 0 0
47 0 0
48 0 0
49 3.1 3.1
50 0 0
51 0 0
52 0 0
53 0 0
54 0 0
55 3.1 3.1
56 0 0
57 0 0
58 0 0
59 0 0
60 0 0
61 0 0
62 0 0
63 0 0
64 0 0
65 0 0
66 0 0
67 0 0
68 0 0
69 0 0
70 0 0
71 0 0
72 0 0
73 0 0
74 0 0
75 3.1 3.1
76 0 0
77 0 0
78 0 0
79 0 0
80 0 0
81 3.1 3.1
82 0 0
83 0 0
84 0 0
85 0 0
86 0 0
IC8003
1 0 0
2 0 0
3 0 0
4 0 0
5 0 0
6 0 0
7 0 0
8 0 0
9 0 0
10 0 0
11 0 2.7
12 0 3.0
13 0 0
14 0 0
15 0 0.3
16 0 0
17 0 0
18 0 0
19 0 0
20 0 0
21 0 0
22 0 0
23 0 0
24 0 2.7
25 0 0
26 2.7 2.7
27 0 0
28 2.7 2.7
29 0.5 0.3
30 2.3 2.2
31 0.5 0.3
32 2.3 2.2
33 0.4 0.3
34 2.3 2.2
35 0 0.3
36 0 2.2
37 0 3.1
38 0.4 0.3
39 0 2.2
40 0 0.3
41 2.2 2.2
42 0.4 0.3
43 2.2 2.3
44 0.3 0.3
45 2.3 2.2
46 0 0
47 3.1 3.1
48 0 0
IC8004
1 0.7 0.7
2 0.5 0.5
3 0 0
4 0 0
IC8006
1 0.7 0.7
2 0 0
3 0 0
4 0 0
5 0.7 0.7
6 0 0
7 0 0.3
8 0 0
9 0 0
10 0 0
11 0 0
12 0 0.7
13 0 0
14 0.4 0
15 0 0
16 0 0
Q8002
E 0 3.1
C 0.7 0.7
B 3.0 3.0
<OP DRV>
MODE
REC PLAY
PIN NO.
MODE
REC PLAY
PIN NO.
IC4802
1 3.1 3.2
2 0 2.6
3 2.6 2.6
4 4.8 4.8
5 0.6 0.6
6 0.6 0.6
7 1.2 1.1
8 0 2.7
9 0 2.6
10 2.6 2.6
11 0 0
12 2.6 2.6
13 2.6 2.6
14 2.6 2.6
IC4804
1 1.6 0.3
2 1.4 2.5
3 1.4 0
4 0 0
5 1.6 2.9
6 1.6 3.0
7 1.9 0
8 4.8 4.8
IC4807
1 1.6 3.0
2 1.6 3.0
3 4.8 4.8
4 0 0
5 1.6 3.0
6 1.6 3.0
7 4.8 0
8 4.8 0
IC4851
1 0 0
2 0.6 0.6
3 0.3 0.3
4 0 0
5 0.3 0.3
6 0 0
7 0 0
8 3.1 3.1
9 4.6 4.6
10 0.5 0.2
11 0 0
12 0.5 0.2
13 4.6 4.6
14 0.2 0.2
15 0 0
16 0.2 0.2
17 0 0
18 0 0
19 0 0
20 0 0
21 0 0
22 0 0
23 0 4.6
24 0 0.1
25 0 0
26 0 0.2
27 0 4.6
28 0.2 0.2
29 0 0
30 0.2 0.2
31 3.1 3.0
32 0 0
33 0 0
34 3.0 3.0
35 3.0 0
36 1.5 1.5
37 1.5 1.5
38 0 0
Q4801
E 0.6 0.6
C 2.1 2.1
B 1.2 1.2
Q4802
E 0 0
C 1.6 3.0
B 0 0
Q4803
E 0 0
C 4.8 4.8
B 0 0
Q4804
E 4.8 4.8
C 1.6 3.0
B 4.8 4.8
Q4805
E 4.8 4.8
C 1.6 3.0
B 4.8 4.8
Q4806
E 1.4 0
C 4.8 4.8
B 2.0 0
Q4851
E 0 0
C 0 3.5
B 0 0
<VIDEO I/O>
MODE
REC PLAY
PIN NO.
IC3201 - -
IC3701
1 0 0
2 1.9 1.9
3 0 0
4 0 0
5 0 0
6 0 0
7 1.9 1.9
8 0 0
9 2.3 2.3
10 0 0
11 1.1 1.1
12 1.1 1.1
13 4.8 4.8
14 1.0 1.0
15 1.0 1.0
16 4.8 4.8
IC3731
1 3.0 3.0
2 1.1 1.2
3 4.8 4.8
4 1.2 1.3
5 0 0
6 1.3 1.4
Q3701
1 1.8 1.6
2 1.2 1.1
3 0 0
4 1.3 1.0
5 0.7 0.4
6 0 0
Q3702
1 0 0
2 0 0
3 0 0
4 4.8 4.8
5 4.4 4.4
6 4.4 4.4
Q3704
E 0.9 0.9
C 0 0
B 0.3 0.3
Q3705
1 0.9 0.9
2 0.3 0.3
3 0 0
4 0.9 0.9
5 0.3 0.3
6 0 0
Q3731
E 0 0
C 4.8 4.8
B 0 0
Q3732
E 0 0
C 0 0
B 3.0 3.0
Q3733
1 0 0
2 0.4 0.4
3 0 0
4 4.8 4.8
5 0 0
6 4.8 4.8
Q3734
E 0 0
C 4.8 4.8
B 0 0
Q3735
1 0 0
2 0 0
3 0 0
4 1.4 1.4
5 0.8 0.8
6 4.8 4.8
<TG>
MODE
REC PLAY
PIN NO.
IC5501
1 0 0
2 3.0 3.0
3 3.0 3.0
4 3.0 3.0
5 0 0
6 3.0 3.1
7 0.3 0
8 0.4 0
9 0 0
10 3.0 3.1
11 1.6 0
12 3.0 3.0
13 0 0
14 1.3 0
15 0 0
16 3.0 3.1
17 2.4 0
18 2.4 0
19 0 0
20 0 0
21 0 0
22 1.4 1.4
23 0 0
24 3.0 3.1
25 0 0.7
26 3.0 0
27 2.5 0
28 3.0 0
29 0 0
30 0.3 2.8
31 0 3.0
32 3.0 0
33 3.0 3.1
34 1.5 0
35 1.4 0
36 3.0 3.1
37 0 0
38 0 0
39 0 0
40 -0.3 0
41 -7.0 0
42 -0.3 0
43 14.9 14.9
44 -7.0 14.9
45 -7.0 14.9
46 0 0
47 0 0
48 3.0 3.0
<MDA>
MODE
REC PLAY
PIN NO.
IC1601
1 0 0
2 0.4 0.4
3 0 0.4
4 0 0
5 0.4 0.5
6 0 0
7 0 0
8 1.6 1.6
9 1.6 1.6
10 1.6 1.6
11 1.6 1.6
12 1.6 1.6
13 1.6 1.6
14 2.8 2.8
15 1.2 1.2
16 1.5 1.5
17 0 1.5
18 0 1.5
19 1.5 1.5
20 1.5 1.5
21 3.1 3.1
22 0 0
23 0 0.4
24 0 1.4
25 1.4 1.4
26 0 11.0
27 0 0
28 2.7 2.7
29 0.7 0.7
30 1.4 1.4
31 0.7 0.7
32 1.0 1.0
33 0 1.3
34 0 0
35 1.3 0
36 0 0
37 0 0
38 0 0
39 0 1.6
40 0 0
41 0 0
42 0 0
43 0 0
44 0 0
45 0 4.7
46 1.5 1.5
47 1.5 1.5
48 1.6 0
49 1.5 1.5
50 0 0
51 - -
52 0 0
53 12.4 12.4
54 0 0
55 0 0
56 0 0
57 0 2.9
58 3.0 3.0
59 0 0
60 1.1 1.1
61 0.3 0.3
62 1.5 1.5
63 0 0.7
64 1.0 0.9
IC1701
1 - -
2 1.5 1.5
3 1.5 1.5
4 0 0
5 1.5 1.5
6 1.5 1.5
7 - -
8 4.7 4.7
IC1702
1 - -
2 1.5 1.5
3 - -
4 0 0
5 - -
6 1.5 1.5
7 - -
8 4.6 4.6
Q1601
1 0 0
2 0 0
3 4.7 4.7
4 0 0
5 4.7 4.6
<PRE/REC>
MODE
REC PLAY
PIN NO.
IC3501
1 0 0
2 0 0.5
3 0 0
4 0 1.6
5 2.8 2.5
6 0 1.5
7 0 0
8 0 0
9 1.3 0
10 1.5 1.5
11 0 3.1
12 0 0
13 4.8 4.8
14 0 0
15 0 0
16 0 0
17 0 0
18 3.8 1.7
19 3.6 1.7
20 3.6 1.7
21 3.8 1.7
22 0 0
23 3.8 1.7
24 3.6 1.7
25 3.6 1.7
26 3.8 1.7
27 0 0
28 1.4 1.3
29 3.6 1.8
30 3.6 1.8
31 1.4 1.2
32 0 0
33 0 0
34 0 0
35 1.8 1.8
36 0.4 0.4
37 3.1 0
38 0 0
39 3.1 0
40 1.5 0
41 0 0
42 3.0 0
43 4.8 0
44 3.1 0
45 0 0
46 0 0
47 0 0
48 4.3 0
49 4.3 2.9
50 0.6 1.6
51 1.4 0
52 0 1.7
53 0 0
54 0 0
55 2.8 1.9
56 1.1 1.1
57 0 0
58 0 1.3
59 0 0
60 0 0
61 3.0 1.9
62 2.8 2.0
63 0 1.4
64 0 1.9
IC3502
1 1.5 0
2 1.5 0
3 0 0
4 1.1 3.1
5 0 3.1
<AUDIO>
MODE
REC PLAY
PIN NO.
IC2201
1 0 1.6
2 0 0
3 0 1.6
4 3.0 3.0
5 3.0 3.1
6 0 0
7 1.5 1.5
8 1.5 1.4
9 1.5 1.6
10 3.0 3.0
11 2.9 2.9
12 0 3.0
13 1.4 0
14 0 0
15 3.0 0
16 0 0
17 0 0
18 0 0
19 1.5 1.5
20 0 0.1
21 1.5 1.5
22 0 2.4
23 0 1.4
24 0 2.4
25 0.8 1.5
26 0 0
27 0 0
28 4.8 4.8
29 0 0
30 2.4 0
31 0 0
32 3.0 0
33 0 1.5
34 0 1.5
35 0 1.5
36 1.5 1.5
37 1.5 0
38 1.5 0
39 0 0
40 1.5 0
41 0 0
42 4.0 0
43 2.7 0
44 4.0 0
45 0 0
46 1.5 0
47 1.5 1.4
48 1.5 0
Q2202
1 0.9 0
2 0.3 0
3 0 0
4 0.9 0
5 0.3 0
6 0 0
Q2401
E 4.0 4.4
C 4.8 4.8
B 4.7 4.8
Q2403
E 3.0 2.9
C 4.8 4.8
B 3.7 3.6
<CAM DSP>
MODE
REC PLAY
PIN NO.
IC4201
1 1.1 0
2 0.6 3.0
3 0.4 3.0
4 0.2 0
5 0 3.0
6 0 0
7 0 0
8 0 0
9 1.0 0
10 3.0 3.0
11 0 0
12 1.4 1.5
13 3.0 3.0
14 2.5 0
15 3.0 0
16 2.4 0
17 2.4 0
18 0 0
19 0 3.0
20 1.9 0
21 0 0
22 1.9 0
23 1.9 0
24 1.2 0
25 3.0 3.0
26 0 0
27 0 0
28 1.4 0
29 1.9 0
30 0.9 0
31 3.0 3.0
32 0 0
33 3.0 3.0
34 0 3.0
35 3.0 3.0
36 1.5 0
IC4202
1 4.8 4.8
2 0 0
3 1.3 1.3
4 3.0 3.0
5 4.8 4.8
IC4301 - -
<USB>
MODE
REC PLAY
PIN NO.
IC8301
1 0.5 0.5
2 1.4 0.3
3 0 0
4 3.0 3.0
5 4.8 4.8
6 0 0
7 0 4.8
8 4.8 4.8
9 4.8 4.8
10 3.1 3.0
11 3.1 3.0
12 0 0
13 0 0
14 2.3 2.2
15 2.3 2.2
16 2.3 2.2
17 2.3 2.2
18 2.3 2.2
19 2.3 2.2
20 0 0
21 3.0 3.1
22 2.3 2.2
23 0 2.2
24 0 0.2
25 0.6 0.3
26 0.6 0.3
27 0.5 0.3
28 0.5 0.3
29 0.5 0.3
30 0.5 0
31 0 0
32 3.1 3.0
33 0.4 0.3
34 0 0
35 2.7 2.7
36 2.6 2.7
37 0 0
38 2.7 2.7
39 0 4.8
40 3.0 3.0
41 0 0
42 0.5 0.4
43 0.3 0.3
44 4.8 4.8
45 0 0
46 0 3.1
47 0 0
48 0 0
<AUDIO AD>
MODE
REC PLAY
PIN NO.
IC2101
1 0 0
2 0 0
3 0 0
4 0 0
5 3.0 3.1
6 3.0 3.1
7 0 0
8 0 0
9 0 0
10 0 0.3
11 0 0
12 0.2 0.3
13 0 0
14 0 0
15 0 0
16 0 0
<FRONT>
MODE
REC PLAY
PIN NO.
MODE
EE
PIN NO.
<MONI-C>
MODE
EE
PIN NO.
<BL2.5>
MODE
EE
PIN NO.
<CCD>
Q9001
1 0 0
2 0.2 0.2
3 0 0
4 0.2 0.2
5 0.9 0.9
6 2.5 2.5
Q9002
1 0 0
2 0.2 0.2
3 0 0
4 0.2 0.2
5 0.9 0.9
6 2.5 2.5
Q9003
E 0 0
C 0.2 0.2
B 0.7 0.7
IC7601
1 0
2 0
3 2.4
4 0
5 0
6 0
7 2.4
8 2.4
9 0
10 12.2
11 0
12 0
13 6.2
14 0
15 6.2
16 0
17 0
18 0
19 6.2
20 1.8
21 1.5
22 1.4
23 0
24 0.4
25 0
26 0.2
27 0.8
28 1.4
29 3.0
30 0.3
31 0
32 0
33 0.4
34 1.4
35 0
36 2.8
37 0
38 0
39 3.0
40 3.0
41 1.5
42 3.0
43 0
44 0
45 3.0
46 2.8
47 2.5
48 2.5
IC7602
1 5.9
2 5.9
3 5.9
4 0
5 4.8
6 4.8
7 7.2
8 12.2
Q7601
E -10.5
C 0
B -9.9
Q7602
E -9.3
C -14.9
B -9.9
Q7603
E -9.9
C 0
B -9.4
Q7604
E -9.9
C -14.9
B -10.5
Q7608
E 0
C 0
B 3.0
Q7609
E 0
C 4.8
B 0
Q7610
E 4.8
C 1.4
B 4.8
IC7504 -
Q7501
E 0
C 4.3
B 0.4
Q7502
E 0
C 4.4
B 0.4
Q7503
E 4.5
C 4.4
B 0
Q7504
E 0
C 0
B 3.0
IC5001
1 -7.1
2 -7.1
3 -0.3
4 -0.3
5 0
6 0
7 0
8 14.9
9 13.8
10 9.8
11 -7.5
12 1.6
13 1.4
14 9.9
Q5001
E 11.3
C 14.9
B 12.1
Q5002
E 0
C 9.9
B 0
VOLTAGE CHARTS
