Controls
1 OPEN/EJECT Switch ............................ pg. 12
2 Stop Button [5] .................................... pg. 21
BACKLIGHT Button ............................. pg. 42
3 Rewind Button [
2
] ............................. pg. 21
NIGHT Button ...................................... pg. 36
4 Play/Pause Button [
4
/6] ....................... pg. 21
5 Fast-Forward Button [
3
] ..................... pg. 21
6 Monitor Open Button [PUSH OPEN] ..... pg. 16
7 Diopter Adjustment Control.................... pg. 10
8 Battery Release Button
[BATT. RELEASE] ................................... pg. 8
9 Recording Start/Stop Button .................. pg. 16
0 MENU Wheel [+, –, PUSH] .................. pg. 44
LCD Monitor BRIGHT (Brightness)
Control [+, –] ........................................ pg. 16
! Snapshot Button
[SNAPSHOT] ....................... pg. 26, 27, 40, 52
@ Power Zoom Lever [T/W]..................... pg. 18
Speaker Volume Control [VOL.] .......... pg. 21
# FOCUS Button..................................... pg. 41
BLANK Button ..................................... pg. 24
$ Lock Button............................................ pg. 17
% Power Switch
[
AUTO
,
MANUAL
, PLAY, OFF] ................. pg. 17
^ INDEX Button
(GR-DVL720/DVL520 only) ................... pg. 29
& INFO Button
(GR-DVL720/DVL520 only) ................... pg. 29
* VIDEO/MEMORY Switch [VIDEO, MEMORY]
(GR-DVL720/DVL520 only) ................... pg. 17
( Video Light Switch
[LIGHT OFF/AUTO/ON]......................... pg. 19
Connectors
The connectors ) to w are located beneath a cover.
) Audio/Video Output Connector
[AV] ............................................ pg. 22, 50, 59
q J Terminal [JLIP (Joint Level Interface Protocol)]
(GR-DVL320 only) ............................... pg. 59
You can also connect to a JLIP-compatible
camcorder or VCR to control it from the
computer using the optional Software HS-V16U.
Edit Connector [EDIT]
(GR-DVL720/DVL520 only) ................. pg. 59
w DC Input Connector ............................. pg. 8, 9
e Digital Video Connector
[DV IN/OUT] (i.Link*) ....................... pg. 51, 65
* i.Link refers to the IEEE1394-1995 industry
specification and extensions thereof. The logo
is used for products compliant with the i.Link
standard.
r S-Video Output Connector
[S-VIDEO] .................................. pg. 22, 50, 59
t PC Connector (GR-DVL320 only) ....... pg. 65
USB (Universal Serial Bus) Connector
(GR-DVL720/DVL520 only) ................. pg. 65
Indicators
y Tally Lamp ....................................... pg. 16, 46
u CHARGE Lamp ....................................... pg. 8
i Power Lamp .................................... pg. 16, 17
Other Parts
o Remote Sensor.................................... pg. 53
Camera Sensor
Be careful not to cover this area, a sensor
necessary for shooting is built-in here.
p Viewfinder .............................................. pg. 10
Q Video Light............................................. pg. 19
W Stereo Microphone ................................ pg. 63
E Viewfinder Cleaning Hatch .................... pg. 74
R Shoulder Strap Eyelets .......................... pg. 10
T Grip Strap .............................................. pg. 10
Y LCD Monitor .................................... pg. 16, 17
U Speaker ................................................. pg. 21
I Battery Pack Mount ................................. pg. 8
O Stud Hole ............................................... pg. 10
P Tripod Mounting Socket ......................... pg. 10
a MEMORY CARD Cover
(GR-DVL720/DVL520 only) ................... pg. 14
