JVC HR-XVC30US - Connecting to a Dolby Digital Decoder or an Amplifier with a Built-In DTS (DVD Deck Only)

74 EN
REMOTE (cont.)
Connecting To A Dolby Digital Decoder
or An Amplifier With A Built-in DTS
(DVD deck only)
These instructions enable you to connect your unit to dolby digital decoder or amplifier with a built-in DTS.
Make connections.
Connect the optical cable between the unit and the
Dolby Digital decoder or amplifier with a built-in DTS.
NOTES:
●
For Dolby digital sound, set “DIGITAL AUDIO OUTPUT” to
“DOLBY DIGITAL/PCM”. (
墌
pg. 79)
●
For DTS sound, set “DIGITAL AUDIO OUTPUT” to “STREAM/
PCM”. (
墌
pg. 79)
CAUTIONS:
●
This unit has a dynamic range of more than 80 dB with regards
to its Hi-Fi audio capability. It is recommended that you check
the maximum level if you are going to listen to the Hi-Fi audio
signals through a stereo amplifier. A sudden surge in the input
level to the speakers may damage them.
●
Some speakers and televisions are specially shielded to
prevent television interference. If both are of the non-shielded
type, do not place the speakers adjacent to the TV set as this
can adversely affect the video playback picture.
Back of unit
Note for connection:
Remove the connector cover from the
unit and remove the protection cap from
the cable.
Optical cable
(not supplied)
Dolby Digital decoder or
amplifier with a built-in DTS
DIGITAL AUDIO OUT
To DIGITAL AUDIO
input
