Switch board
Block No. [0][2][0][0]
R797 NRS181J-100X MG RESISTOR 10
Ω
1/8W J
R798 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R801 NRS181J-103X MG RESISTOR 10k
Ω
1/8W J
R803 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R804 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R805 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R807 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R808 NRS181J-102X MG RESISTOR 1k
Ω
1/8W J
R809 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R811 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R812 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R813 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R814 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R815 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R817 NRS181J-472X MG RESISTOR 4.7k
Ω
1/8W J
R818 NRS181J-473X MG RESISTOR 47k
Ω
1/8W J G200
R822 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R823 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R824 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R825 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R826 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R827 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R828 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R829 NRS181J-473X MG RESISTOR 47k
Ω
1/8W J
R830 NRS181J-223X MG RESISTOR 22k
Ω
1/8W J
R831 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R832 NRS181J-223X MG RESISTOR 22k
Ω
1/8W J
R833 NRS181J-472X MG RESISTOR 4.7k
Ω
1/8W J
R834 NRS181J-223X MG RESISTOR 22k
Ω
1/8W J
R835 NRS181J-472X MG RESISTOR 4.7k
Ω
1/8W J
R836 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R840 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R841 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R842 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R843 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R844 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R861 NRS181J-471X MG RESISTOR 470
Ω
1/8W J
R862 NRS181J-471X MG RESISTOR 470
Ω
1/8W J
R863 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R864 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R901 NRSA63J-912X MG RESISTOR 9.1k
Ω
1/16W J
R902 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R903 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R904 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R905 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R906 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R907 NRSA63J-393X MG RESISTOR 39k
Ω
1/16W J
R908 NRSA63J-683X MG RESISTOR 68k
Ω
1/16W J
R909 NRSA63J-273X MG RESISTOR 27k
Ω
1/16W J
R910 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R911 NRS181J-473X MG RESISTOR 47k
Ω
1/8W J
L501 QQL231K-4R7Y INDUCTOR I/M 4.7uH K
L561 QQL231K-4R7Y INDUCTOR I/M 4.7uH K
L562 QQL231K-4R7Y INDUCTOR I/M 4.7uH K
L701 QQL231K-4R7Y INDUCTOR I/M 4.7uH K
L801 QQL231K-4R7Y INDUCTOR I/M 4.7uH K
L802 QQL231K-4R7Y INDUCTOR I/M 4.7uH K
L901 QQR0703-001 CHOKE COIL
CJ321 QNN0533-001 PIN JACK
AR20
0
CJ321 QNN0519-001 SURROUND JACK G200
CJ701 QNB0100-002 CAR ANT JACK
CN501 QGB2027M4-22S CONNECTOR B-B (1-22)
CN801 VMC0334-001 CONNECTOR
CN901 QNZ0611-001 16P CONNECTOR
TU701 QAU0311-001 TUNER PACK
X561 QAX0714-001Z C RESONATOR 16.000MHz
X801 QAX0759-001Z CRYSTAL
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
IC661 PT6523LQ IC
IC681 RPM7338-V4 REMOCON RCV
AR20
0
Q670 2SB624/4/-X TRANSISTOR
Q671 UN2211-X TRANSISTOR
D630 SML-310LT/MN/-X LED
D631 SML-310VT/JK/-X LED
D632 SML-310VT/JK/-X LED
D633 SML-310VT/JK/-X LED
D634 SML-310VT/JK/-X LED
D635 SML-310VT/JK/-X LED
D636 LNJ308G81/1-3/X LED
AR20
0
D636 SML-310VT/JK/-X LED G200
D637 LNJ308G81/1-3/X LED
AR20
0
D637 SML-310VT/JK/-X LED G200
D638 SML-310VT/JK/-X LED
D639 SML-310VT/JK/-X LED
D640 SML-310VT/JK/-X LED
D641 SML-310VT/JK/-X LED
D642 SML-310VT/JK/-X LED
D643 SML-310VT/JK/-X LED
D644 SML-310VT/JK/-X LED
D645 SML-310VT/JK/-X LED
D646 SML-310VT/JK/-X LED
D647 SML-310VT/JK/-X LED
D648 SML-310VT/JK/-X LED
D649 SML-310VT/JK/-X LED
D650 SML-310VT/JK/-X LED
D651 SML-310VT/JK/-X LED
D652 NSPW310BS/B2RS/ LED
D653 NSPW310BS/B2RS/ LED
D661 MA111-X SI DIODE
D662 UDZS5.1B-X Z DIODE
D681 MA8062/M/-X Z DIODE
AR20
0
C661 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C662 NCS31HJ-681X C CAPACITOR 680pF 50V J
C663 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C681 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
AR20
0
C686 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C687 NCB31HK-223X C CAPACITOR 0.022uF 50V K
R601 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R602 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R603 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R604 NRSA63J-911X MG RESISTOR 910
Ω
1/16W J
R605 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R606 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R607 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R608 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R609 NRSA63J-911X MG RESISTOR 910
Ω
1/16W J
R610 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R611 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R612 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R613 NRSA63J-911X MG RESISTOR 910
Ω
1/16W J
R614 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R615 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R630 NRSA02J-821X MG RESISTOR 820
Ω
1/10W J
R631 NRSA02J-471X MG RESISTOR 470
Ω
1/10W J
R633 NRSA02J-681X MG RESISTOR 680
Ω
1/10W J
R637 NRSA02J-471X MG RESISTOR 470
Ω
1/10W J
AR20
0
R637 NRSA02J-821X MG RESISTOR 820
Ω
1/10W J G200
R639 NRSA02J-331X MG RESISTOR 330
Ω
1/10W J
R641 NRSA02J-331X MG RESISTOR 330
Ω
1/10W J
R643 NRSA02J-471X MG RESISTOR 470
Ω
1/10W J
R645 NRSA02J-471X MG RESISTOR 470
Ω
1/10W J
R647 NRSA02J-471X MG RESISTOR 470
Ω
1/10W J
R649 NRS181J-391X MG RESISTOR 390
Ω
1/8W J
