2-17
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
CN963
CN964
CN892
S891
S892
S893
S894
S895
S896
(Panel switch board)
(Connector board)
Reverse side
(Panel switch board)
(Connector board)
Forward side
Connector board
